Broadcast LCD Monitor
- shenzhen
- Credit Card
You May Like
Product Details
| Products Status | Stock | Application | Desktop | |
| Screen Size | Other, 24" | Response Time | 5ms | |
| Brightness | 500cd/m | Interface Type | DVI, S-Video, YPBPR | |
| Contrast Ratio | 800:1 | Resolution | 1366 x 768 | |
| Widescreen | Yes | Panel Type | TFT | |
| Pixel Pitch | 0.213 | Brand Name | user | |
| Model Number | US-BC2401 | Place of Origin | Guangdong, China |
Product Description
Specifications
the world's most advanced system on chip technology, ecactly color display,fast response time, high quality broadcasting monitor
Product parameter | |
Product model | US-BC2401 |
display size | 24 |
display pixel | 1920×1200 |
OSD ratio | 16:10 |
video input/output | 1×BNC |
Y/C input/output | 1×DIN |
Composite(YPbPr/YCbCr) input/output | 3×BNC(support 1080p format) |
SD/HD-SDI video input/output | 2×BNC HD/SD auto-detection |
audio input/output | 2×RCA dimensional sound |
Speaker | 3W×2 |
remote control | RS-232 |
TV system | PAL/NTSC/SECAM(auto-identification) |
dual-screen (PIP/PBP) | YES |
dual-screen switching | YES |
Color temperature selecting | 9300K,6500K,5600K,Customized |
Tag selector | Center mark, the proportion of tags, security area, filling |
Chroma vector | yes |
Luminance distribution histogram | yes |
Black and white mode | yes |
Full Blue mode | yes |
Scan mode | Full-scan, over scan |
Display ratio | 16:9,4:4,Full-screen, input image ratio ,1:1( dot to dot) |
Tally light | Color bright red and green LED lights channel tips |
Pixel pitch | 0.270×0.270(mm) |
Color display | 16.7M |
Response Time | 8ms |
Brightness | 500cd/m2 |
Contrast | 1000:1 |
