PTC Heater
- Shenzhen
- Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | BZH | |
| Model Number | BZH/ 275+ 70*10*3.1 AC |
Product Description
Specifications
self-control the temperaturevoltage: 12Vto 240V
safety and higher reliable
give out heat continuously
keep steady power
PTC Heater is a kind of new surface-insulated .It is called all-purpose PTC heater by fixing two metal electodes with two leads on both side of general PTC element.
Metal electrode having assemblied a pair of belt fuse in two flanks side of average PTC component, Yellow insulative film, Structure are still simple in the metal electrode outward appearance on envelop.
The simple-structure heater gives out constant-temperature heat and does not need any additional temperature applications.
The high insulation-intension heater has many advantage as follow:
1. simple structure heater gives out constant-temperature heat and not need any additional temperature applications.
2. safety
3. give out heat continuously and keep stady power
4. It is used in a large range of voltage
5. longer service time
6. Higher reliability
7. dimension is nimble various, may need according to customer reality book make various type specifications.
The PTC Heating element is used for hair permanent clamp ,hair curler,face sauna,heat preservation plate,electric mosquito killer,physical therapy apparatus,hot melt glue gun
Product model
| name of the product | length | width | thickness | temperature | voltage | the length of the cable |
| ptc heating element | 70mm | 13mm | 3.1mm | 275 Centidegree | 220V/110V | 150mm(length as per your request) |
| PTC Heater element | 70mm | 12mm | 3.1mm | 255 Centidegree | 220V/110V | 155mm(length as per your needed) |
| PTC Heating element | 64mm | 12mm | 2.9mm | 230 Centidegree | 220V/110V | 250MM(length as per your interested in) |
| electric Heating element | 52mm | 12mm | 3.1mm | 180 Centidegree | 220V/110V | 150mm(length as per your request) |
| PTC Heating element | 35mm | 10mm | 2.8mm | 220 Centidegree | 220V/110V | 55mm( as per your interested in ) |
| PTC Heating element | 24mm | 8mm | 3.1mm | 160 Centidegree | 220V/110V | 120mm( length as per your needed) |
| PTC heating element | 24mm | 6mm | 2.6mm | 150 Centidegree | 220V/110V | 125mm(length as per your request) |
Above information all could customized the orders as per your specifications.
