Plastic Injection Moulding Machine With Different Tonnage
US$ 11,500 - 850,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, thermoplastic & thermosetting
Style:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gallon Bottle Preform Injection Molding MachineUS$ 11,500 - 130,000MOQ: 1 Set -
Plastic Bottle Machine MakerUS$ 15,500 - 95,000MOQ: 1 Set
-
PET PP Automatic Plastic Cup Lid Making MachineUS$ 11,500 - 850,000MOQ: 1 Set
-
Cup Thermoforming Machine in ChinaUS$ 11,500 - 850,000MOQ: 1 Set
-
PE,PP,PVC,EVA Bottle Production MachineUS$ 15,500 - 95,000MOQ: 1 Set
Condition
New
Type
Other, thermoplastic & thermosetting
Style
Horizontal
Brand Name
Longsheng
Model Number
LSF-308
Place of Origin
Jiangsu, China
Plastic Type
Other, injection moulding
Automatic
Yes
Injection Weight
738-1004g
Injection Rate
177-239g/s
Clamping Force
3080KN
Opening Stroke
590
Power(W)
48KW
Certification
ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
High rigidity,long working lifeEnergy saving 20% to 80%
Timely after-sales services
Accurate flexible low rejection rate
plastic injection moulding machine with different tonnage,welcome contact for more details
LSF-308 Technicial specification
|
INJECTION UNIT |
Unit |
LSF-308 |
|||
A |
B |
C |
|||
Screw Diameter |
Mm |
60 |
65 |
70 |
|
Screw L/D Ratio |
L/D |
21.6 |
20 |
18.6 |
|
Short Size |
Cm3 |
811 |
952 |
1104 |
|
Injection weight |
G |
738 |
866 |
1004 |
|
Injection Rate |
g/s |
177 |
206 |
239 |
|
Plasticizing capacity |
g/s |
41 |
49 |
57 |
|
Injection Pressure |
Mpa |
193 |
164 |
142 |
|
Screw Speed |
Rpm |
0-185 |
|||
|
CLAMPING UNIT |
Clamp Force |
KN |
3080 |
||
Space Between Tie Bars |
mm |
630*630 |
|||
Toggle Stroke |
mm |
590 |
|||
Max. Mold Height |
mm |
630 |
|||
Min. Mold Height |
mm |
200 |
|||
Ejector Stroke |
mm |
160 |
|||
Ejector Tonnage |
KN |
62 |
|||
Ejector Number |
P |
9 |
|||
|
OTHERS |
Max. pump Pressure |
Mpa |
16 |
||
Pump motor powder |
Kw |
30 |
|||
Heater Power |
Kw |
18 |
|||
Machine Dimension(L*W*H) |
M |
6.15*1.57*2 |
|||
Machine Weight |
T |
10.2 |
|||
Some of the important features:
- Clamping system: Faster response, steable and high rigidity
- Injection system: Accurate and flexible, lower rejection rate
- Control system: Computer and simple operation,molding data memory system
- Power system: Energy saving, high efficient and precise
- Metal parts: The thickness of our frame, metal plate and wallboard are thicker than other company.
Other Information
- Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production
- Visiable lubrication system: on time clean, avoid cast steel parts abrasion and broken.
- Oil treasure: Filter of hydraulic oil,good for pump and valves
- Long working life: Imported spare parts and updated version
- Aftersales service: Professional & timely
