Summary of KYN61-40.5 Removable AC Metal-clad Switchgear 33kv Switchgear :
KYN61-40.5 removable AC metal-clad switchgear (short for switchgear as below) applies to 40.5kV, 3 phase, AC and 50/60 Hz electrical power network for receiving and distributing power energy and also for control, monitor and protect ion. It is applicable in general power system and occasions with frequent operation. The product conforms to GB3906: 3~35kV AC Metal Enclosed Switchgear, IEC60694 & GB/T 11022: The common technical clauses of HV Switchgear and controlgear Standard, DL/T404-1997: Order Technical term of Indoor AC HV Switchgear and IEC62271-200 1~52kV AC Metal Enclosed Switchgear and controlgear standard.
Technical Specification of KYN61-40.5 Removable AC Metal-clad Switchgear 33kv Switchgear :
Structure of KYN61-40.5 Removable AC Metal-clad Switchgear 33kv Switchgear :
The switchgear divides into enclosure and handcart, the enclosure is made of aluminium-zinc plated steel sheet after processed by CNC machine and multi-bending, then is assembled with bolts. So it has strong mechanical strength and can guarantee the neatness and good appearance. It consist of relay compartment, handcart compartment, cable degree is IP2 X when CB handcart is on opening and testing position.
The switchgear is metal-clad removable, main circuit adopts composite insulation processing, emergency spreading to other parts. CT and earthing switch are mounted in cable compartment and busbar compartment. The protection degree of enclosure is IP3X, the protection and large space for several cables. The structural design o f new completely insulated VCB or SF6 CB and spring operating mechanism is integrated console model with such excellence of well exchange and simply change.
Ambient Condition of KYN61-40.5 Removable AC Metal-clad Switchgear 33kv Switchgear :
1. Ambient temperature: -10℃ ~40℃ , daily average: ≤35℃ ;
2. Altitude: ≤1000m;
3. Relative humidity: daily average ≤95%, monthly average ≤90%;
4. Earthquake intensity: ≤8 degree;
5. Applicable occasions should be free from corrosives, inflammables and vapour.
Product Feature of KYN61-40.5 Removable AC Metal-clad Switchgear 33kv Switchgear :
The switchgear is an assembly unit and the circuit breaker adopts handcart floor model. It owns simply change and well exchange after equipping with advanced composite insulation vacuum circuit breaker. Lead screw nut propulsion mechanism is installed in the handcart frame for preventing from fault operating and damaging propulsion mechanism, the handcart can be remove easily; All of the operation steps can be carried out at closing condition; It is compulsory locking among main switch, handcart and panel door to meet five protection; wide space for connecting several cable in cable cubicle. Earthing switch is used in earthing and loop short circuit, protection degree of enclosure is IP3X, IP2X under opening condition.
Certifications:
Cooperation Projects:
Company Pict:
Huayi Electric Co., Ltd. is the core subsidiary of Huayi Elec. Apparatus Group Co., Ltd. In 2007, It became the first ShangHai Stock Exchange (SSE) listed electric company in WenZhou. The company has more than 1,500 employees, of these 30 percent is engineers. It has 7 core subsidiaries and 4 divisions. It focuses on two main industries: wind energy and electric apparatus. Huayi Electric Co., Ltd has created a complete marketing network to cover the business of State Grid Corporation, five power generation Groups, chemical, petroleum, railways, industries and manufacturing. It as well has established perfect worldwide marketing channels and after-sales service system in Europe, Asia, Africa, America, and Oceania.
Main Products List:
1. Wind Turbines
2. Switchgear Panels
3. High Voltage Components
4. Instrument & Protection Systems
5. Instrument Transformers & Accessories
6. Outdoor Power Transmission & Distribution Systems
Sample & OEM & ODM is OK.
More information pls kindly visit our website:
/
http://heag.en.china.cn/
Switchgear panels; switchgear; high voltage switchgear; 33kv switchgear; 11kv switchgear; schneider switchgear; low voltage switchgear; medium voltage switchgear; gas insulated switchgear; electric switchgear; electrical switchgear; 11kv switchgear panel; medium voltage switchgear manufacturers; switchgear cabinet; 22kv switchgear; Box Transformer Substation; switch cabinet; switchboard; high voltage switch cabinet; high tension switch cabinet; Mvnex; GGD ; GCK ; Blokset; switch cubicle; air insulated high-voltage switchgear; compartmented switchgear panel; Ring main Unit; cubicle switchgear; compartmented switchgear; metalclad switchgear; metal-enclosed switchgear
gas-filled switchgear; insulation-enclosed switchgear;
