Ship Elevator

Ship Elevator photo-1
US$ 10,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
composed
After-sales Service Provided:
Overseas third-party support available
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name composed
After-sales Service Provided Overseas third-party support available

The types of our products include home villa elevator, marine elevator, clean elevator,explosion -proof elevator, mine lift, debris elevator ,stereo lifting equipment, special passenger, freight elevators, other customized production of elevator.Our elevators are greatly appreciated in a variety of different markets throughout the world

load(kg) rate of speed car size well size opening size pit depth overhead height generator room size
360 0.63/1.0 1100*900 1750*1900 700 >=1500 >=4000 1750*2500
450 0.63/1.0 1350*900 2000*1900 700 >=1500 >=4000 2000*2500
630 0.63/1.0 1400*1100 2100*2100 0 >=1500 >=4000 2100*2500
800 0.63/1.0 1400*1350 2100*2350 800 >=1500 >=4000 2100*2500
1000 0.4 1400*1500 2250*2250 900 >=1500 >=4000 2250*2500
100 0.4 800*800 1300*1200 800 NO >=2500 1300*2200
200 0.4 800*800 1300*1200 800 NO >=2500 1300*2200
300 0.4 1000*1000 1500*1400 1000 NO >=2500 1500*2400

ship elevator



ship elevator





The main configuration

items

Parts name

brand

producing area

comments

1

Control cabinet

Microcomputer control system

Step

Shanghai

Assembly

Variable frequency driving

step

Shanghai

Master contactor

Schneidder

Shanghai(joint venture)

Relay

Omron

Shanghai(joint venture)

Air switch

Delixi

Shanghai(joint venture)

Phase sequence

Ait

Ningbo

2

Tractor

Permanent magnet trction machine

Tongrun

Suzhou

Assembly

Rotary encoder

Heidenhain

France

3

Maneuvering box

maneuvering box panel

Ok

Shanghai



microcomputer operation panel

Xinshida

Shanghai



display in the cabin

Xinshida

Shanghai



4

Calling box out cabin

calling board out cabin

OK

Shanghai



Display of showing floors

Xinshida

Shanghai



5

Cabin

cabin assembly

Kangchi

Shanghai



emergency power supply in the cabin

OK

Shanghai



6

Safety parts



speed governor

Olin

Shanghai



Safety tongs

Letian

Shanghai



buffer

Lvdun

Shanghai



light curtain

Weike

Ningbo(joint venture)



7

 steel rope

Tianshen

Tianjin



8

 Door opener

permanent magnet synchromous motor

Best/Zhanpeng

Shanghai/Zhanpeng



Frequency converting contro

Best/Zhanpeng

Shanghai/Zhanpeng



Machine parts

Best/Zhanpeng

Shanghai/Zhanpeng



9

 Rail

Hongcheng

Suzhou



10

Rail bracket

Kangchi

 Shanghai



11

 Traveling cable

Changshun

Shanghai



12

 Cabin door

Kangchi

 Shanghai



13

Landing door

Kangchi

 Shanghai



14

Little door frame

Kangchi

Shanghai



The above is the standard configuration. If you want have a high quality, the configuration can be adjust. But it cannot be lower than the basic configuration.
