Composed brand ship elevator 800KG
The types of our products include home villa elevator, marine elevator, clean elevator,explosion -proof elevator, mine lift, debris elevator ,stereo lifting equipment, special passenger, freight elevators, other customized production of elevator.Our elevators are greatly appreciated in a variety of different markets throughout the world
| load(kg) | rate of speed | car size | well size | opening size | pit depth | overhead height | generator room size |
| 360 | 0.63/1.0 | 1100*900 | 1750*1900 | 700 | >=1500 | >=4000 | 1750*2500 |
| 450 | 0.63/1.0 | 1350*900 | 2000*1900 | 700 | >=1500 | >=4000 | 2000*2500 |
| 630 | 0.63/1.0 | 1400*1100 | 2100*2100 | 0 | >=1500 | >=4000 | 2100*2500 |
| 800 | 0.63/1.0 | 1400*1350 | 2100*2350 | 800 | >=1500 | >=4000 | 2100*2500 |
| 1000 | 0.4 | 1400*1500 | 2250*2250 | 900 | >=1500 | >=4000 | 2250*2500 |
| 100 | 0.4 | 800*800 | 1300*1200 | 800 | NO | >=2500 | 1300*2200 |
| 200 | 0.4 | 800*800 | 1300*1200 | 800 | NO | >=2500 | 1300*2200 |
| 300 | 0.4 | 1000*1000 | 1500*1400 | 1000 | NO | >=2500 | 1500*2400 |
The main configuration
items |
Parts name |
brand |
producing area |
comments |
|
1 |
Control cabinet |
Microcomputer control system |
Step |
Shanghai |
Assembly |
Variable frequency driving |
step |
Shanghai |
|||
Master contactor |
Schneidder |
Shanghai(joint venture) |
|||
Relay |
Omron |
Shanghai(joint venture) |
|||
Air switch |
Delixi |
Shanghai(joint venture) |
|||
Phase sequence |
Ait |
Ningbo |
|||
2 |
Tractor |
Permanent magnet trction machine |
Tongrun |
Suzhou |
Assembly |
Rotary encoder |
Heidenhain |
France |
|||
3 |
Maneuvering box |
maneuvering box panel |
Ok |
Shanghai |
|
microcomputer operation panel |
Xinshida |
Shanghai |
|
||
display in the cabin |
Xinshida |
Shanghai |
|
||
4 |
Calling box out cabin |
calling board out cabin |
OK |
Shanghai |
|
Display of showing floors |
Xinshida |
Shanghai |
|
||
5 |
Cabin |
cabin assembly |
Kangchi |
Shanghai |
|
emergency power supply in the cabin |
OK |
Shanghai |
|
||
6 |
Safety parts
|
speed governor |
Olin |
Shanghai |
|
Safety tongs |
Letian |
Shanghai |
|
||
buffer |
Lvdun |
Shanghai |
|
||
light curtain |
Weike |
Ningbo(joint venture) |
|
||
7 |
steel rope |
Tianshen |
Tianjin |
|
|
8 |
Door opener |
permanent magnet synchromous motor |
Best/Zhanpeng |
Shanghai/Zhanpeng |
|
Frequency converting contro |
Best/Zhanpeng |
Shanghai/Zhanpeng |
|
||
Machine parts |
Best/Zhanpeng |
Shanghai/Zhanpeng |
|
||
9 |
Rail |
Hongcheng |
Suzhou |
|
|
10 |
Rail bracket |
Kangchi |
Shanghai |
|
|
11 |
Traveling cable |
Changshun |
Shanghai |
|
|
12 |
Cabin door |
Kangchi |
Shanghai |
|
|
13 |
Landing door |
Kangchi |
Shanghai |
|
|
14 |
Little door frame |
Kangchi |
Shanghai |
|
|
The above is the standard configuration. If you want have a high quality, the configuration can be adjust. But it cannot be lower than the basic configuration.
Shanghai Kangchi Mechanical & Electrical Equipment Co., Ltd was established in 2002, is a set design , manufacture, sales, installation and service in one of the modern lift production enterprises, products various type of elevators, is the China Elevator Association Member. Kangchi is located in the center of Yangtze River Delta, 30 minutes distance to Pudong Airport, 1 hour reach Yangshan Deep-Water Port. Shanghai.
Service
As one of the leader of manufacturer for customized elevator, Shanghai Kangchi Elevator focus on stringent safety criterion in international elevator industry. In order to provide professional services for the modernization market, Shanghai Kangchi Elevator has built a professional modernization team with experienced and skilled engineers. According to the various special requirements from the clients, Shanghai Kangchi Elevator will provide more reliable, more maturity and more economy solutions.
Installation
The final assembly of elevators are conducted on site, which is the most important chain in assembly. We can send professional project manager to be responsible for internal planning, coordination, distribution of labor, project quality management and safety management of the installation project. Prior to the launch of each project, the project manager shall hold internal inaugural meeting to develop construction scheme and exchange technical documentations, and develop emergency scheme according to actual situations, so as to guarantee the project is completed in line with quality requirements and without delay. We constantly develop the latest elevator installation workmanships in order to remain at the world-leading level. Compared with traditional elevator installation workmanships, installation without scaffold saves a lot of trouble in erecting and dismantling scaffolds, standardizes installation procedures, shorten the installation period and improve its quality. Shanghai Kangchi Elevator will provide you with best product quality, best project quality and best service quality.
Maintenance
We have always attached great importance to the development of maintenance technologies. And, in the light of properties and application environment of different elevators, we has developed unique maintenance procedures as well as special computer and tools. In addition to routine maintenance, we will inspect your elevator periodically with special presumptive diagnostic technology and develop personalized maintenance scheme according to your elevator’s operation conditions, to protect against possible troubles and maximize its operation time.
Renewal and Alteration
We will appropriately apply new technology, feature and material to in-service elevator to expand its functions, improve operation reliability and traveling comfort, and further satisfy special demands of customers.
And actively absorb the international advanced technology, and strive to create outstanding national brand. Kangchi Elevator are full of confidence with you to create a more brilliant future.
GENERAL BUSINESS FAQ
1, Regarding any inquiry from Alibaba, Kangchi Elevator will provide you the prompt feedback and professional solution/quotation within 24 hours.
2, All above specifications are based on Kangchi Elevator . standard configuration and only for equipment price which does not include adjustment, assembling after goods arrived at the destination/customer's jobsite.
3, Terms of payment: 30% down payment by TT within 3 days after order released to Kangchi Elevator , balanced by T/T within 7 days before shipment.
4, Lead time: 25 days from the date in receipt of down payment, confirmation of Specification & Layout Drawings.
5, Guarantee: The quality guarantee is 12 months after the delivery.
6, Quotation validity: One month since the date of release.
