ZX7124 SMALL MILLING MACHINE
US$ 1900 - 2500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
RUNFA
Place of Origin:
China
Model Number:
ZX7124
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
15 days
Related Products
-
Small Drilling and Milling Machine ZXTM40US$ 800 - 860MOQ: 1 Set -
Small Drilling and Milling Machine ZX50CUS$ 1,100 - 2,390MOQ: 1 Set
-
Drilling and Milling Machine ZX7550CW(Vertical and Horizontal)US$ 2,000 - 3,200MOQ: 1 Set
-
Drilling and Milling Machine ZX6350C(Vertical and Horizontal)US$ 2,800 - 3,800MOQ: 1 Set
-
Drilling and Milling Machine ZX6350D(Vertical and Horizontal)US$ 3,200 - 4,200MOQ: 1 Set
Brand Name
RUNFA
Place of Origin
China
Model Number
ZX7124
Type
Vertical
Certification
CE ISO9001
After-sales Service Provided
No overseas service provided
Warranty
13 Months
Weight
650kg
Dimension(L*W*H)
1300 x 1000 x 1700
Voltage
220V/240V/380V/440V
Condition
New
Power(W)
2.2KW
CNC or Not
Normal
Specification |
UNIT |
ZX7124 |
Spindle taper |
|
7:24 ISO 40 |
Distance between spindle nose and table surface |
mm |
60-500mm |
Distance between spindle axis and column guideway |
mm |
310mm |
Spindle speed range |
rpm |
8 steps 115-1750 rpm |
Table size |
mm |
1000mm x 240 mm |
Table travel(X,Y) |
mm |
550mm x 320mm |
Main motor power |
kw |
2.2kw(two- speed) |
Swivel angle of milling head |
° |
±45°
|
Overall dimension |
mm |
1300 x 1000 x 1700 |
N.W/G.W |
kg |
600/650 |
