Specifications
1.simple structure2.Easy operation
3.Stable function
4.Motion agility
5.Easy transit,fix and maintenance
1.Powered by compressed air,to meet the needs of production safety efforts percussion and vibration frequency can be controlled by adjusting the air pressure.
2.Use of high-strength cast iron,light weight,small size.
3.Mechanism is simple,easy to operate.
The principle of work:
Motor through reduction gear and crank rod driven compression cylinder compression piston moves up and down to produce compressed air.
When the compression cylinder upper and lower airways to the atmosphere,the compressed air does not enter the cylinder,motor idling,
hammer does not work,the handle or lever or pedal down rotary valve,the compressed air into the working cylinder of the upper or lower,
to promote working piston moves up and down,so as to drive the hammer and iron on rise or fall,complete a variety of hit actions.
MAIN TECHNICAL DATA
Item | Unit | Numerical Value | |
Weight of falling parts | kg | 16 | |
Maximum blow energy | J | 180 | |
Distance from center of die to frame | mm | 150 | |
Distance between top and bottom die | mm | 180 | |
Number of blows per minute | min-1 | 258 | |
Dimension of top to bottom | mm | 70*40 | |
Diameter of the working cylinder | mm | 115 | |
Diameter of the compressing cylinder | mm | 125 | |
Travel distance of malleus | mm | 210 | |
Travel distance of plunger | mm | 120 | |
Forges | Round | mm | Φ22 |
| Square | mm | 20 |
Motor | Power | kw | 1.5 |
| Rotate speed | rpm | 1440 |
Outside Size | Length | mm | 800 |
| Width | mm | 420 |
| High | mm | 1170 |
Base plate weight | kg | 40 | |
Hammer weight | kg | ~290 | |
PICTURES DISPLAY
Manufacture(my company) will in charge of the technical service for the whole using life of the machine.
If you want to know more about the machine ,pls. contact with us freely.
