Help CenterCat5e UTP Rj45 Keystone Jack
Related Products
-
Cat3 UTP 8P6C Keystone JackUS$ 0.16 - 0.26MOQ: 10000 Pieces -
CAT6A RJ45 Modular JackUS$ 0.3 - 0.8MOQ: 1000 Pieces
-
Cat6 UTP Modular JackUS$ 0.5 - 0.9MOQ: 500 Pieces
-
China UTP Rj45 Cat6 Keystone JackUS$ 0.2 - 0.8MOQ: 1000 Pieces
-
180 Degree White CAT5e UTP Rj45 Keystone JackUS$ 0.315 - 0.63MOQ: 1000 Pieces
Cat6 UTP rj45 Keystone Jack Description:
Industry standard:
1)Meet TIA-568-A and TIA/A-568-B
2)Available in Cat5e, T568A, T568B wiring. meeting every cabling requirement
3)High reliability and superior performance
Electrical:
Voltage rating: |
125 vac RMS |
Current rating: |
1.5 amp |
Contact resistance: |
100 milliohms max |
Insulation resistance: |
1000 megohms min @ 500 vdc |
Dielectric strength: |
750 vac RMS 60Hz, 1min |
Environmental:
1. Storage: -40° To +85°
2. Operation: 0° To 70°
Conform to tia/eia 568b
Mates with modular plug conforming to FCC part 68, subpart f.
Mechanical:
1. Housing material: PC UL94v-0
2. Insert material: Flame retardancy ABS UL94v-0
3. PCB material: Fr-4 thickness: 1.6mm
4. Contact material: Phosphor bronze stamp pin t=0.35mm
5. Idc contact material: Phosphor bronze t=0.50mm with nickel plating
6. Wire: Awg 24-26
| cat5e/cat6 | UTP | red,blue,white |
| tooless | accept 22-26AWG | 3U"15U"30U",50U"gold plating |
| print your logo available |
packing picture:
