School Drawing Paper Making Machine

Name: School Drawing Paper Making Machine
Brand: Dingchen
SKU: 103022407

US$ 45,000 - 600,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

Dingchen

Zhengzhou Dingchen Machinery Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name Dingchen

Model Number series type

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

high quality a4 paper making machine with reasonable price

1.Technical datas of a4 paper making machine:

1.Raw material: waste paper, cotton straw, wheat straw, sugar cane bagasse

2.Output paper: writing paper, culture paper, newspaper, printing paper,a4 paper

3.Weight: 60-120g/m2

4.Net paper width: 2100mm

5.Rail gauge: 3000mm

6.Capacity: 20T/D

7.Drive way: Motors with AC converter frequency & adjustable speed .Processing transmission

2.Main frame of a4 paper making machine:

Part name	Equipment	Specification	Qty(set)
Mesh cylinder part	Cylinder mould	Φ1500mm×2400mm	3
	Net slot	12 thick polyethylene plastic sheet welding	3
	Couch roll	Φ450mm×2400mm	1
	Reverse roll	Φ450mm×2400mm	1
Press part	Stone roll	Φ650mm×2400mm	1
	rubber roll	600mm×2400mm	1
	Pneumatic loaded device
Dryer part	Dry can	Φ2500mm×2400mm	2
	Dry can	Φ1500mm×2400mm	3
	Touch roll	Φ650mm×2400mm	1
	Pneumatic loaded device, shore hardness is 90^o±2, second and third cylinder part are equipped with dry wire. & anti-pressure device
Designed type	Rack is square box, cast iron, All-pneumatic pressure
Drive	Reduction box, coupling, adjustable speed
