Specifications
Output paper:Writing paper, printing paper, newsprint paper, kraft paper.
Technical data:
Output paper:Writing paper, printing paper, newsprint paper, kraft paper.
Weight::50-200g/m2
Net paper width:3200mm
Rail gauge:4300mm
Working speed:350m/min
Dynamic balancing speed:500m/min
Driving speed:400m/min
Capacity:100T/D
Drives:AC frequency conversion speed regulator .
Processing transmission
Main frame of the equipment:
Head-box section:Especially chose open type headbox, which comprises step diffuser,
perforaled roll, and so on.The step diffuser is Grade 3,which is
made of organic glass.The top and bottom lip are made of stainless
steel, and can be global and local regulation.
Fourdrinier section:The length of fourdrinier table is 1800mm,and the stand is
welded with section steel, except the draw-out position with
aluminum alloy. Fourdrinier section comprises breast board
roll, forming board, slice, suction box, suction flat box, suction
couch, electric tightener, pneumatic corrector, cut squirt and so on.
Press partUse suction feed paper leader, a series of vacuum press
and three series of straight-through press.
Dryer part:dryer canΦ1500mm×3800mm34
The arrangement of dryer cans are 6+6+ 6+8+ sizing machine+8,
adopt sealed gear drive, thin oil lubricating.
Drives andcontrol:AC frequency conversion speed regulator, processing
transmission, digital sealed ring control system.
Calender & winding partEquipped with super calender and horizontal winding machine.
All the accessory equipment
Number |
Equipment |
QTY |
|
|
3200mm fourdrinier and multi-cylinder cultural paper making machine |
1 set |
2. |
3200mm winding machine |
1 set |
3. |
3200mm rewinding machine |
1 set |
4. |
3200mm calender |
1 set |
5. |
35m3 potcher |
6 sets |
6. |
Pulp pump(6″) |
14 sets |
7. |
Pulp pump(4″) |
12 sets |
8. |
Vertical pressure screen |
4 sets |
9. |
450 Double disks refiner |
4 sets |
10. |
Decker thickener |
4 sets |
11. |
Kamyr pressure filter |
4 sets |
12. |
Sand separator pump |
2 sets |
13. |
Sand cleaner |
4 sets |
14. |
8m3 high consistency hydraulic pulper |
3 sets |
15. |
Resin tank |
6 sets |
16. |
Chemical mixing tank |
4 sets |
17. |
The whole set of work bench |
1 suite |
18. |
Φ1000Thruster |
12 sets |
Supply of expendables:
Number |
Equipment |
Qty |
Price(RMB) |
|
1 |
10T Boiler |
1 set |
1,200,000 |
|
2 |
Electric closet |
8 sets |
104,000 |
|
3 |
Control cubicle |
2 set |
240,000 |
|
4 |
All the motors and electrical appliance |
|
520,000 |
|
5
|
Polyester wire |
10 pcs |
150,000 |
|
6
|
Felt |
10 pcs |
150,000 |
|
7
|
Bleaching tower |
2 set |
120,000 |
|
8
|
Waste water processing equipment |
1 suite |
3,600,000 |
perfect service:
(1) technical consultation
(2)detailed design of factory
(3)installing and testing the whole production line;
(4)training engineers and workers;
(5)supplying spare part for long time;
