Specifications
1. Raw material: wood pulp ;
2 output paper style: A4 paper;
3. Capacity: 1.5T/D;
4 high quality
Technical parameters
1. Raw material: wood pulp ;
2 output paper style: A4 paper;
3. Capacity: 1.5T/D;
4. Output paper weight: 80-140g/m2;
paper width: 900mm;
6. Width of copper cylinder: 1100mm;
7. Rail gauge:1300mm;
8. Drive way: AC inverter speed,section drive;
main structure and characteristic of main part
1. Cylinder section: φ800mm×1100mm stainless steel cylinder mould 2(pcs), φ250mm×1100mm couch roll 3(pcs),reverse roll 1 (pcs),
coated by rubber,rubber hardness HSD 38°C±2.
section: φ260mm×1100mm marble roll 1 pcs, φ250mm×1100mm rubber roll 1 pcs, ccoated by rubber,rubber hardness HSD 90°C±2.
Mechanical loading device.
3. Dryer section: φ1000mm×1100mm alloy dryer can 2 pcs, φ250mm×1100mm touch roll 1pcs,coated by rubber,
Rubber hardness HSD 90°C±2,mechanical loading device.
4.Drive and control section: AC inverter speed,section drive;
All Equipments
NO. |
Item |
qty(set) |
1 |
787mm paper Machine |
1 |
2 |
double layer dryer can Exhausted hood |
1 |
3 |
φ400mm axial-flow ventilator |
1 |
4 |
Model-33 Roots vacuum pump |
1 |
5 |
Suction box |
2 |
6 |
3m3 High consistency hydrapulper |
1 |
7 |
0.9m2 High frequency vibration screen |
1 |
8 |
φ250mm single disc Refiner |
1 |
9 |
sand remover(6 set) |
1group |
10 |
φ500mmThruster |
2 |
11 |
4 inch pulp pump |
5 |
12 |
work table |
1 |
13 |
1ton boiler(burn coal) |
1 |
