hot! 3200 mm 100 ton/day newspaper cultural paper machine
Technical data:
Output paper:Writing paper, printing paper, newsprint paper, kraft paper.
Weight:50-200g/m2
Net paper width:3200mm
Rail gauge:4300mm
Working speed:350m/min
Dynamic balancing speed:500m/min
Driving speed:400m/min
Capacity:100T/D
Drives:AC frequency conversion speed regulator .
Processing transmission
Main frame of the equipment:
Head-box section:Especially chose open type headbox, which comprises step
diffuser, perforaled roll, and so on.The step diffuser is Grade 3,which is
made of organic glass.The top and bottom lip are made of stainless steel,
and can be global and local regulation.
Fourdrinier section:The length of fourdrinier table is 1800mm,and the stand
is welded with section steel, except the draw-out position with aluminum
alloy. Fourdrinier section comprises breast board roll, forming board,
slice, suction box, suction flat box, suction couch, electric tightener,
pneumatic corrector, cut squirt and so on.
Press part:Use suction feed paper leader, a series of vacuum press and three
series of straight-through press.
Dryer part: dryer canΦ1500mm×3800mm34 The arrangement of dryer cans
are 6+6+ 6+8+ sizing machine+8, adopt sealed gear drive, thin oil
lubricating.
Drives andcontrol:AC frequency conversion speed regulator, processing
transmission, digital sealed ring control system.
Calender & winding part: Equipped with super calender and horizontal winding
machine.
All the accessory equipment:
Number |
Equipment |
QTY |
|
1. |
3200mm fourdrinier and multi-cylinder cultural paper making machine |
1 set |
2. |
3200mm winding machine |
1 set |
3. |
3200mm rewinding machine |
1 set |
4. |
3200mm calender |
1 set |
5. |
35m3 potcher |
6 sets |
6. |
Pulp pump(6″) |
14 sets |
7. |
Pulp pump(4″) |
12 sets |
8. |
Vertical pressure screen |
4 sets |
9. |
450 Double disks refiner |
4 sets |
10. |
Decker thickener |
4 sets |
11. |
Kamyr pressure filter |
4 sets |
12. |
Sand separator pump |
2 sets |
13. |
Sand cleaner |
4 sets |
14. |
8m3 high consistency hydraulic pulper |
3 sets |
15. |
Resin tank |
6 sets |
16. |
Chemical mixing tank |
4 sets |
17. |
The whole set of work bench |
1 suite |
18. |
Φ1000Thruster |
12 sets |
Flow chart of paper making:
Picture of pulp making:
Workshop of paper machine manufacturing:
Picture of working paper machine:
Finished paper products:
Picture of packaging and loading:
Our clients:
Perfect service:
(1)technical consultation
(2)detailed design of factory
(3)installing and testing the whole production line;
(4)training engineers and workers;
(5)supplying spare part for long time.
If you are interested in, please contract us:
In order to improve our working efficiency we have some question for you ?
· What kind of paper you want to make ?
· What is you productivity ?
· What is you raw material ?
· You want to make the big roll paper or daily use small paper ?Please tell us in you inquiry . Thank you .
