Specifications
1.CE2.Automatic braking system
3.Low noise lever
4.Remote control
5.Low rated torgue,low request to air
1.Product parameters and advantages:
Rated power |
60KW |
Max power |
65KW |
Output voltage |
690V |
Rated wind speed |
10m/s |
Rotor diameter |
8m |
Blade material |
FRP |
Start-up wind speed |
3m/s |
Work wind speed |
3-25m/s |
Rotation speed |
60r/min |
Number of blades |
7 |
Turbine weight |
3500kg |
Tower height |
18m |
Tower type |
Steel (Q235B) |
Output controller system |
Controller , Inverter |
1. Low starting torque
2. Low start-up wind speed
2. Low speed permanent magnet generator.
3. No vibration & low noise.
4. All of our products confirm to CE.
5. Reliable wind power system by multifunction controller.
6. PWM constant voltage recharge function provides stable output.
7. On-grid or Off-grid wind power system optional.
8. 1-year warranty for generator and 18-20 years service life.
9. Electronic brake and manual brake, optional.
10. High efficiency and Low mechanical resistance energy loss.
11. Special sealed wind turbines, moisture, sand and water proof.
2.Control System:
|
ON-GRID Control system |
Controller |
|
Rated output voltage of generator:AC690v Rated output current:70A way of protection:Manual,brake,unload. Operating environment temperature:-10℃~40℃ Relative humidity:30%~90%,>90%(No condensation) Operating environment height:<2000m Protective level:IP44 Way of cooling:enforcement Noise:30-40dB |
|
Inverter |
|
Output way of power:three phase/four lines Rated power:100KW Normal voltage:380v±3% Normal frequency:50Hz±0.05 Waveform:pure sine wave Distortion of total sinusoidal:linear load 5%,nonlinear load <8% Dynamic load and voltage transient:<5% Overload capacity:overload125% 2min,overload 150% 1min Working temperature of environment:-10℃~40℃ Relative humidity:<90% Relative humidity:<2000m(100m increase 1% decreases) Way of cooling:enforcement air-cooled(temperature controlled) Noise :50-65dB |
3.Connection Mode
4.Notes
a. Tower type and tower height can be changed according to customer’s requirement.
b. Working voltage can be adjusted according to customer’s requirement.
c. For the details, please feel free to contact us.
