Specifications
1.50kw Vertical Axis wind turbine2. Low starting torque
3. Low speed permanent magnet generator
4. Lose noise
|
1.Advantages: 1.Low starting torque.
2.Low start wind speed.
3.Low speed permanent magnet generator.
4.No vibration & low noise.
5.All of our products confirm to CE .
6.PWM constant voltage recharge function provides stable output.
7.Reliable wind power system by multifunction controller.
8.On-grid or Off-grid wind power system optional.
9.2-year warranty for generator and 20-25 years service life.
10.Electronic brake and manual brake, optional.
11.High efficiency and Low mechanical resistance energy loss.
12. Special sealed wind turbines, moisture, sand and water proof.
|
2.Company information:
Qingdao Richuan Precision Machinery Co., Ltd. is a high-tech company located in Qngdao,engaged in the research,development,production,sales and service o small-and medium-scale wind turbines.
Our main products include horizontal axis and vertical axis wind turbines,off-grid and grid-connected,solar panels and wind-solar hybrid lighting systerms.These units are now widely used in agricultural and pastoral areas,mountainous areas,island,frontier defense sentry station,observatories and other areas with insufficient electricity and rich wind resources.
3.Product infomation :
| Rated power | 50KW |
| Max power | 55KW |
| Output voltage | 690V |
| Rated wind speed | 14m/s |
| Rotor diameter | 8m |
| Blade material | FRP |
| Start-up wind speed | 3m/s |
| Work wind speed | 3-25m/s |
| Rotation speed | 80r/min |
| Number of blades | 9 |
| Turbine weight | 1500kg |
| Tower height | 18m |
| Tower type | Steel (Q235B) |
| Output controller system | Controller , Inverter |
| 50kw Vertical Axis Wind Turbine Generator OFF-GRID | |
| Rated power | 50KW |
| Max power | 55KW |
| Output voltage | 360V |
| Rated wind speed | 14m/s |
| Rotor diameter | 8m |
| Blade material | FRP |
| Start-up wind speed | 3m/s |
| Work wind speed | 3-25m/s |
| Rotation speed | 60r/min |
| Number of blades | 9 |
| Turbine weight | 754kg |
| Tower height | 18m |
| Tower type | Steel (Q235B) |
| Output controller system | Controller , Inverter |
4.Control Systerm:
5.Buyers Need to Know :
(1)Note:
1.Tower type and tower height can be changed as per your request.
2. Working voltage can be special requested.
3. For the details,please feel free to contact us.
(2)Market:
High quality and competitive price guarantee us a huge market all over the world , such as in Eastern Asia , Europe , North America ,South America and Middle East .
6.Site Choosing:
7.Pictures for your referance:
The permanent magnet generator:
Blades:
The inverter:
Controller:
Tower:
Package:
7.CE
