50kw Horizontal Wind Turbines Price,micro Hydro Generator,low Rpm Permanent Magnet Alternator

Specifications

1.50kw Horizontal Axis Wind Turbine Generator
2. Low starting torque
3. No vibration & low noise
4. Low start-up wind speed

1.Product Description:



1.Low starting torque

2.Low start wind speed

3.Low speed permanent magnet generator

4.No vibration & low noise

5.All of our products confirm to CE

6.PWM constant voltage recharge function provides stable output

7.Reliable wind power system by multifunction controller

8.On-grid or Off-grid wind power system optional

9.1-year warranty for generator and 18-20 years service life.

10.Electronic brake and manual brake, optional.

11.High efficiency and Low mechanical resistance energy loss.

12. Special sealed wind turbines, moisture, sand and water proof



2. Company profile



Qingdao Richuan Precision Machinery Co., Ltd. is a high-tech company located in Qngdao,engaged in the research,development,production,sales and service o small-and medium-scale wind turbines.



Our main products include horizontal axis and vertical axis wind turbines,off-grid and grid-connected,solar panels and wind-solar hybrid lighting systerms.These units are now widely used in agricultural and pastoral areas,mountainous areas,island,frontier defense sentry station,observatories and other areas with insufficient electricity and rich wind resources.



3.Product infomation :



50KW Horizontal axis Wind Turbine Generator On-grid
Rated power	50KW
Max power	55KW
Output voltage	360VDC
Rated wind speed	12m/s
Rotor diameter	18m
Blade material	FRP
Start-up wind speed	3m/s
Work wind speed	3-25m/s
Rotation speed	60r/min
Number of blades	3
Turbine weight	2050kg
Tower height	18m
Tower type	Steel (Q235B)
Output controller system	Controller , Inverter



50KW Horizontal axis Wind Turbine Generator Off-grid
Rated power	50,000W
Max power	55,000W
Output voltage	DC360V/AC220
Rated wind speed	12m/s
Rotor diameter	18.0m
Blade material	FRP
Start-up wind speed	3m/s
Work wind speed	3-25m/s
Rotation speed	60r/min
Number of blades	3pcs
Turbine weight	2200kg
Tower height	18m
Tower type	Steel (Q235B)
Suggested battery type	12V150AH120pcs
Service life	20-25 years



4.Note:



1.Tower type and tower height can be changed as per your request.

2. Working voltage can be special requested.

3. For the details,please feel free to contact us.



High quality and competitive price guarantee us a huge market all over the world , such as in Eastern Asia , Europe , North America ,South America and Middle East .



5.Control Systerm:





6. Pictures for your referance:



























7.CE
