UHF Portable Handheld RFID Reader With Win CE 6.0 and GPRS

Specifications

915M UHF Portable Handheld RFID Reader MS-7000U

MS-7000U has Optional modules including 1D/2D barcode scanning, RFID cards/tags reading under UHF protocols, WiFi/GPRS/Bluetooth communication, GPS positioning and image capturing. Rugged structure with IP64 rating, better dust-/wafer-proof capability and 1.5 m drop survival to concrete to ensure high performance under various extremely environments.

Various function modules such as infrared, fingerprint, thermal printer can be integrated according to specific project requirements.

Physical characteristics:

Dimensions: 186.5*75*48 mm

Weight: < 500 g (with battery)

Screen: 3.2” QVGA backlight TFT-LCD, 65 K colors. 240 x 320 (QVGA size)

Touch panel: Glass analog resistive touch

Battery: Rechargeable li-ion polymer battery (3.7 V/ 4,000 mAh)

Expansion slots: SIM/SAM,SD (TF) card

Input method: Touch input or keyboard input

Audio: 0.5 watt

Keyboard: Numeric, full alphanumeric

Programming Environment:

.NET / C++ programming using Microsoft Visual Studio 2005&2008 or higher

Software Development Kits (SDK) provided

Operation system:

Windows Embedded CE 6.0 core /Windows Embedded CE 6.0 pro

Environmental:

Operating temperature: -20 °C ~ 50 °C

Storage temperature: -25 °C ~ 70 °C

Humidity: 5% RH ~ 95% RH (non-condensing)

Dropping survive: 1.5-meter drop test on six sides (concrete floor, under operating temperature range)

Environment sealing: IP64

Performance:

CPU: Samsung ARM920T@533 MHz

Memory: 128 MB RAM/1 GB Flash

Expansion memory: 2G SD, max 8G

Interfaces:USB 2.0;  RS232(optional)

Barcode scanner:

1D laser scanner: Symbol SE955

Types: UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS

2D scan engine: Symbol SE4500

Types: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code,

Aztec, MaxiCode;

Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX)

UHF:
Operating frequency:

China: 840MHz~845MHz/ 920MHz~925MHz

Europe: 865MHz~868MHz

Protocol: EPC GEN2/ ISO 18000-6C

Read range up to: 2.5 m

Antenna: 3dBi

Power: +10dBm~+30dBm

Wireless Communication:

GPRS/GSM(900/1800 MHz)

WiFi: IEEE802.11b/g

Bluetooth: Class II, 3-5m

GPS:

Module: u-blox NEO-5Q

Performance: 50-channel u-blox 5 positioning engine,internal GPS

Localization time: hot start-1 sec,warm start-38 secs,cold start-42 secs

Camera:

Samsung 3.2 mega pixels,2048 (H)*1536 (V), QXGA
