Specifications
MS-9801S integrated RFID UHF readerA*with 10m long distance
B*integrated with antenna
C*IP65
D*SDK+help develop software
MS-9801S integrated RFID UHF reader with 10m long distance
Shandong Mingwah Aohan Smart Technology Co., Ltd. focuses on providing customers with the highest quality RFID system solutions. With15 year’s experience, SDMW formed a leading RFID project management team, which is able to tailor various RFID system solutions according to the characteristics of the industry and the needs of different enterprises. A complete RFID solution including: RFID tags, Readers, Middleware and Application software, SDMW has many proven solution cases in low frequency (LF) / high frequency (HF) / ultra high frequency (UHF) / microwave applications , such as “ RFID tracking system resource management”, “Laundry management systems”, “RFID product line management system”, “Asset tracking systems”, “RFID warehouse management system”…
MS-9801S integrated RFID UHF reader Introduce
- Built-in 12dBi Horizontal linear Polarization antenna,the max reading distance is 10M
- The reader is made of ABS material which have the function of waterproof, anti-jamming, anti-thunder
- The reader use for item identification and data acquisition.
MS-9801S integrated RFID UHF reader Application:
- Transport management:Highway,Railway transport administration and container transportation
- Vehicle management
- bridge toll fee
- Going Through Customs management
- Warehousing and Logistics management
- Parking system
- Access control
- Production processes management
- Anti-counterfeiting product
MS-9801S integrated RFID UHF reader pictures
MS-9801S integrated RFID UHF reader Specification
| |
Work frequency |
FCC ISM 902~928MHz or ETSI 865.6 - 867.6 MHz |
Work mode |
3 Modes: master-slave,timing,Trigger |
Power |
+15dBm~+32dBm |
Antenna |
Built-in 12dBi Horizontal linear Polarization |
Interface |
RS-232,RS-485,Wiegand 26 bits34bits,LAN (optional) |
Communication rate |
Up to 57,600bps |
Tag protocol |
Sahara |
Reading distance |
Depend on the reader and tag |
Reading distance |
>10M |
Writing distance |
>5M |
Mounting bracket |
Two type for choose |
Software platform |
1)API |
Power supply |
+9V~18V DC, less than 3 Amps |
Adapter |
AC110~220V/DC +12V |
Size/Weight |
450x450x40 mm 3.4KG |
Work temp |
-30°C~+75°C |
Store temp |
-45°C~+95°C |
Protect grade |
IP65 |
Certification |
FCC CMII TELEC ETSI |
