Specifications
UHF RFID Handheld Reader with Win CEUHF RFID Handheld Reader with IP64
Latest RFID Reader with GPRS
UHF Handheld Terminal
915M UHF RFID Handheld Reader MS-7000U
MS-7000U has Optional modules including 1D/2D barcode scanning, RFID cards/tags reading under UHF protocols, WiFi/GPRS/Bluetooth communication, GPS positioning and image capturing. Rugged structure with IP64 rating, better dust-/wafer-proof capability and 1.5 m drop survival to concrete to ensure high performance under various extremely environments.
Various function modules such as infrared, fingerprint, thermal printer can be integrated according to specific project requirements.
Physical characteristics:
Dimensions: 186.5*75*48 mm
Weight: < 500 g (with battery)
Screen: 3.2” QVGA backlight TFT-LCD, 65 K colors. 240 x 320 (QVGA size)
Touch panel: Glass analog resistive touch
Battery: Rechargeable li-ion polymer battery (3.7 V/ 4,000 mAh)
Expansion slots: SIM/SAM,SD (TF) card
Input method: Touch input or keyboard input
Audio: 0.5 watt
Keyboard: Numeric, full alphanumeric
Programming Environment:
.NET / C++ programming using Microsoft Visual Studio 2005&2008 or higher
Software Development Kits (SDK) provided
Operation system:
Windows Embedded CE 6.0 core /Windows Embedded CE 6.0 pro
Environmental:
Operating temperature: -20 °C ~ 50 °C
Storage temperature: -25 °C ~ 70 °C
Humidity: 5% RH ~ 95% RH (non-condensing)
Dropping survive: 1.5-meter drop test on six sides (concrete floor, under operating temperature range)
Environment sealing: IP64
Performance:
CPU: Samsung ARM920T@533 MHz
Memory: 128 MB RAM/1 GB Flash
Expansion memory: 2G SD, max 8G
Interfaces:USB 2.0; RS232(optional)
Barcode scanner:
1D laser scanner: Symbol SE955
Types: UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS
2D scan engine: Symbol SE4500
Types: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code,
Aztec, MaxiCode;
Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX)
UHF:
Operating frequency:
China: 840MHz~845MHz/ 920MHz~925MHz
Europe: 865MHz~868MHz
Protocol: EPC GEN2/ ISO 18000-6C
Read range up to: 2.5 m
Antenna: 3dBi
Power: +10dBm~+30dBm
Wireless Communication:
GPRS/GSM(900/1800 MHz)
WiFi: IEEE802.11b/g
Bluetooth: Class II, 3-5m
GPS:
Module: u-blox NEO-5Q
Performance: 50-channel u-blox 5 positioning engine,internal GPS
Localization time: hot start-1 sec,warm start-38 secs,cold start-42 secs
Camera:
Samsung 3.2 mega pixels,2048 (H)*1536 (V), QXGA
