8m~10m Reading Range UHF RFID Scanner -Factory Since 1992 Accept Paypal

US$ 220 - 450 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

M&W

Model Number:

UHF rfid scanner

Shandong Mingwah Aohan Smart Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name M&W

Model Number UHF rfid scanner

Specifications

8-10M reading distance UHF RFID scanner
*TCP/IP ,Weigand 26 ,RS232 of UHF reader
*UHF RFID scanner used for parking system

Specification
Work frequency	860MHz~928MHz (can customized as clients requirement)
Protocol	ISO18000-6B,EPC Class 1,EPC Class 1 GEN 2, Container tag,Railway tag
Work mode	Broad spectrum(FHSS) or fixed frequency,can set by software
Antenna	Built-in 12 dBi vertical polarization antenna (linear polarization)
Max RF output power	30 dBm
Power flatness	<0.5 DB
Output adjusting range	20~30 dBm,can set by software
Reading mode	Timing,trigger or software command reading, the mode can set as client's requirement
Reading time	<8ms for a card.
Reading/writing time	Reading 8bytes <5ms,writing 4bytes<25ms
Reading/writing distance	<8m,writing distance is 70% reading distance
Communication interface	Type A:RS-232,RS-485,Wiegand26/34 Type E:RS-232,Wiegand,Ethernet
Input/output interface	1 road trigger input,2 road relay
Power source	DC 9V adapter
Power consumption	≤5W
Size	450mm450mm50mm
Package size	540mm540mm140mm
Gross weight	4.82kg
Net weight	2.66kg
Work temp.	-45°C~+75°C (-49°F~ 167°F)
Storage temp.	-50°C~+85°C (-58°F~ 185°F)
Work state indicator	Buzzer
Certification	FCC CE RoHS
