CK578 CE small single column cnc vertical lathe
- 100 Set / Sets per Month
- Dalian China
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Vertical | CNC or Not: | CNC |
Automatic Grade: | Automatic | Max. Swing Diameter: | 800mm | Place of Origin: | Liaoning, China |
Brand Name: | LFM | Model Number: | CK578 cnc vertical lathe | Voltage: | Customer's Requirement |
Power(W): | 22kW | Dimension(L*W*H): | 2080x2621x2935mm | Weight: | 7500kgs |
Certification: | ISO9001:2008 & CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CK578 CE small single column cnc vertical lathe
1. I.D. & O.D. cylindrical turning,
2. end-facing,
3. I.D. & O.D. cone turning,
4. grooving,
5. threading;
6. boring, drilling, reaming, etc.
Specifications | Unit | Parameter |
Table diameter | mm | 720 |
Max. Turning diameter | mm | 800 |
Max. Height of workpiece | mm | 600 |
Max. Weight of workpiece | kg | 2000 |
Speed range of table | r/min | 11.5~460 |
Steps of table |
| two grades stepless |
Torque of table | N·m | 2500 |
Max. Cutting force of railhead | KN | 8000 |
Power of main motor | KW | 22 |
Travel distance of railhead (horizontal) | mm/ min | 710 |
Travel distance of railhead (vertical) | mm/ min | 600 |
Feed range of railhead | mm/ min | 0.1—1000 |
Rapid traverse of railhead | mm/ min | 3000 |
S.N. | Name | Remark |
1 | Table |
|
2 | Table base |
|
3 | Vertical column |
|
4 | Crossbeam(fixed) |
|
5 | Rail head |
|
6 | Main motor |
|
7 | Operation panel |
|
8 | Manual 4-jaw chuck |
|
9 | Electrical six-position turret |
|
kinds of colors for your choice/can be customized
No cover:
Semi-cover
