J23-125T Mechnical Accentric Press Machine

US$ 19,811 - 19,811 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

Normal

Power Source:

Mechanical

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Power Source Mechanical

Place of Origin Liaoning, China

Brand Name LFM

Model Number J23-125T

Voltage 220V,380V,440V 50/60Hz

Power(W) 11kW

Dimension(L*W*H) 1600x2200x3100mm

Certification ISO9001, CE

Warranty 12 months after delivery

After-sales Service Provided Engineers available to service machinery overseas

J23-125T Accentric Press Machine Technical Data

Features:

Casting body,
inclinable body.
horizontally placed crankshaft is used;
rolling bearing is used instead of copper bush with lower noise and longer service life;
J23-80 and the upon models adopt balance cylinders;
Manual shut height adjustment with scale display;
High accuracy, high efficiency, simple and convenient operation, good performance, favorable price and best service.

Main Usage:

Specifications	Unit	Parameter
Nominal pressure	KN	1250
Slipper stroke	mm	140
Stroke times	Time/min	50
Max. closing height	mm	450
Adjustment of closing height	mm	80
Throat depth	mm	320
Pole distance	mm	420
Bench size(L and R)	mm	920
Bench size(F and B)	mm	580
Bench hole(Dia.)	mm	280
Bench hole size (L and R)	mm	400
Bench hole size(F and B)	mm	220
Size of punch shank hole(Dia.)	mm	60
Size of punch shank hole(Depth)	mm	80
Bench thickness	mm	130
Dimension	mm	F and B: 1600 L and R: 2200 Height: 3100
Main motor power	kW	11
N.W/G.W	kg	7500/9000
Packing size	mm	3400×1900×2500
