J23-40T Mechnical Accentric Power Press Machine

US$ 7,223 - 7,223 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

Normal

Power Source:

Mechanical

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Power Source Mechanical

Place of Origin Liaoning, China

Brand Name LFM

Model Number J23-40T

Voltage 220V,380V,440V 50/60Hz

Power(W) 4kW

Dimension(L*W*H) 1400x2000x2300mm

Certification ISO9001, CE

Warranty 12 months after delivery

After-sales Service Provided Engineers available to service machinery overseas

J23-40T Accentric Press Machine Technical Data

Features:

Casting body,
inclinable body.
horizontally placed crankshaft is used;
rolling bearing is used instead of copper bush with lower noise and longer service life;
J23-80 and the upon models adopt balance cylinders;
Manual shut height adjustment with scale display;
High accuracy, high efficiency, simple and convenient operation, good performance, favorable price and best service.

Main Usage:

Specifications	Unit	Parameter
Nominal pressure	KN	400
Slipper stroke	mm	80
Stroke times	s.m.p	55
Max. closing height	mm	240
Adjustment of closing height	mm	60
Throat depth	mm	200
Pole distance	mm	300
Thickness of bench	mm	75
Bench size (L and R)	mm	500
Bench size (F and B)	mm	320
Size of slipper (L and R)	mm	250
Size of slipper (F and B)	mm	220
Size of punch shank hole (Dia.)	mm	50
Size of punch shank hole (Depth)	mm	70
Dimension	mm	F and B: 1400 L and R: 1000 Height: 2300
Main motor power	KW	4
Weight	kg	2500
