Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module

Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module thumbnail-1
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module thumbnail-2
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module thumbnail-3
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module thumbnail-4
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module thumbnail-5
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module thumbnail-6
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module photo-1
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module photo-2
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module photo-3
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module photo-4
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module photo-5
Malaysia 190K Tunnel Kiln Ceramic Fiber Module Thermal Insulation Material for Oven Low Density Ceramic Fiber Module photo-6
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Yao Xing
Model Number:
YXTX-489
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Yao Xing
Model Number YXTX-489
Application heat insulation material, Furnace Insulation
Grade HA (High Aluminum)
Dimensions 300*300*200/250mm
Working Temperature 1200℃, 1200℃
Fiber Diameter 3μm
Thermal Conductivity 0.045
Shrinkage (1800℉, 3h) <3%

Product Description



190K ceramic fiber module



Product Series:



1.1050 Ceramic Fiber Module YXTX-189

2.1260 Ceramic Fiber Module YXTX-289

3.1260 Ceramic Fiber Module YXTX-389

4.1400 Ceramic Fiber Module YXTX-489

5.1400 Ceramic Fiber Module YXTX-589





Characteristic:



Ceramic fiber folded module not only used in furnace, but also brought following benefit with ended custom: :

1.Folded blanket will impact tight with each other in differently way

without gaps after release from packing.

2.Elastically fiber blanket can withstand mechanical force.

3.The elasticity of fiber blanket could make up distortion of furnace casing and with gaps between modules.

4.Because of the light weight, the decalescence capability is low as the insulation materials.

5.Low thermal conductivity can save much energy.

6.Excellent thermal shock resistance capability.

7.Can be betaken immediately as soon as being installed, for there is no need to be dried and maintained.

8. The Anchor system should be far away from the hot surface of the modules and kept in the lower temp.

 Malaysia 190K tunnel kiln ceramic fiber module thermal insulation material for oven low density ceramic fiber module



Technical Index:



Classification Temperature

1050

1260

1400

Code

YXTX-189

YXTX-289

YXTX-389

TXTX-489

TXTX-589

Shrinkage on Heating (%)

950°C×24h

≤-3

1000°C×24h

≤-3

1100°C×24h

≤-3

1200°C×24h

≤-3

1350°C×24h

≤-3

Theoretical Density (kg/m3)

200±10

Shot Content

(φ≥0.25mm)(%)

≤15

Theoretical

Thermal Conductivity

(W/m·k)

0.050-0.060(200°C)

0.095-0.120(400°C)

0.160-0.195(600°C)

 Al2O3 (%)

≥44

≥45

≥45

52-55

38-40

Al2O3+SiO2 (%)

≥96

≥97

≥99

≥99

-

ZrO2 (%)

-

-

-

-

15-17

Al2O3+SiO2+ ZrO2 (%)

-

-

-

-

≥99

Fe2O3 (%)

≤1.2

≤1.0

≤0.2

≤0.2

≤0.2

K2O+Na2O (%)

≤0.5

≤0.5

≤0.2

≤0.2

≤0.2

 Specification (mm)

300×300×200,According to your requirements

Package

Woven Bag/Carton

Quality Control System

ISO9001-2000 ,ISO14001-1996



Application:



Furnace lines of various industrial furnace and heating equipment in metallurgy, machine, construction and material, petrol-chemical and ferrous metal industry.



1.Oil heaters



2.Reformer



3.Forge furnaces



4.Process heaters



5.Preheating furnaces



6.Crude oil heaters



7.Fume incinerators



8.Tunnel kilns



9.Cracking Furnaces



10.Shuttle kilns



11.Annealing furnaces



 Malaysia 190K tunnel kiln ceramic fiber module thermal insulation material for oven low density ceramic fiber moduleMalaysia 190K tunnel kiln ceramic fiber module thermal insulation material for oven low density ceramic fiber moduleMalaysia 190K tunnel kiln ceramic fiber module thermal insulation material for oven low density ceramic fiber moduleMalaysia 190K tunnel kiln ceramic fiber module thermal insulation material for oven low density ceramic fiber moduleMalaysia 190K tunnel kiln ceramic fiber module thermal insulation material for oven low density ceramic fiber module
