X5028 Small Knee Type Universal Vertical Milling Machine

US$ 5,074 - 7,971 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

LFM

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Liaoning, China

Brand Name LFM

Model Number X5028(1200x280mm) vertical milling machine

Type Universal

CNC or Not Normal

Voltage 220V/380V/415V/440V/480V

Power(W) 3kW

Dimension(L*W*H) 1635x1680x1810mm

Weight 1500kgs

Certification CE; ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

X5028 vertical milling machine Technical Data

Product Introduction

vertical milling machine has following features:

1. one more powerful metal cutting machine,

2. high rigidity,

3. wide range of spindle feed also can bear a heavy burden.

4. the spindle taper hole can install many kinds of cylindrical cutter, disc cutter, form cutter, end milling cutter and so on,

5. optional accessories as dividing head, rotary table, machine vice,milling chuck, Digital readout, can make such machine more functional.

Main Usage:

6. Suitable for machining all parts plane, inclined plane, groove, hole,keyway, etc,

7. for machinery manufacturing, mould, apparatus, instrument, car and motor car.

Main Technical Data

SPECIFICATIONS	UNIT	Parameter
Table Size	mm	1200 × 280
Table Travel (X, Y, Z)	mm	680/260/400
Spindle nose to work surface	mm	35~435
Spindle taper		7:24 ISO40
Rapid speed of table (X, Y, Z)	mm	1000/1000/500
Table feed ( X, Y, Z )	mm	(8) 10~400 (X, Y)
T-slots ( NO:/ width/pitch )	mm	3/14/70
Spindle speed range	r.p.m	12steps 35~1500
Spindle travel	mm	70
Distance between spindle axis and colomn guidway	mm	285
Swovel angle of Vertical milling head		±30°
Main motor	kW	3
3 to feed motor feed	kW	0.75
Overall size	mm	1635 × 1680 ×1810
Net weight	kg	1500
