Specifications
Refractory ceramic fiber module for boiler insulation1.Low thermal conductivity
2.Excellent corrosion resistance
Product Series:
1. 1050 Ceramic Fiber Module YXTX-189Z
2. 1260 Ceramic Fiber Module YXTX-289Z
3. 1260 Ceramic Fiber Module YXTX-389Z
4. 1400 Ceramic Fiber Module YXTX-489Z
5. 1400 Ceramic Fiber Module YXTX-589Z
Description:
A series of ceramic fiber folded module was processed according the fiber module structure,size by
special machine on the ceramic fiber needle blanket which was corresponding material. In the course of
processing, they should be maintained a certain proportional reduction, to ensure that compressed to form a integer set without joint between ceramic fiber folded blanket after ceramic fiber folded module have
been built. Owing to the ceramic fiber folded module expand differently. Ceramic fiber folded module
could be fixed to the stud which in the steel board of industrial furnace by series of anchors.
Characteristic:
Ceramic fiber folded module not only used in furnace, but also brought following benefit with ended
custom:
1. Folded blanket will impact tight with each other in differently way without gaps after release from
packing.
2. Elastically fiber blanket can withstand mechanical force.
3. The elasticity of fiber blanket could make up distortion of furnace casing and with gaps between
modules.
4. Because of the light weight, the decalescence capability is low as the insulation materials.
5. Low thermal conductivity can save much energy
6. Excellent thermal shock resistance capability.
7. Can be betaken immediately as soon as being installed, for there is no need to be dried and maintained.
8. The Anchor system should be far away from the hot surface of the modules and kept in the lower temp.
Application:
Furnace lines of various industrial furnace and heating equipment in metallurgy, machine, construction and material, petrol-chemical and ferrous metal industry.
Technical Index:
Classification Temperature |
1050 |
1260 |
1400 |
||
Code |
YXTX-189Z |
YXTX-289Z |
YXTX-389Z |
TXTX-489Z |
TXTX-589Z |
Shrinkage on Heating (%) |
950°C×24h≤-3 |
1000°C×24h≤-3 |
1100°C×24h≤-3 |
1200°C×24h≤-3 |
1350°C×24h≤-3 |
Theoretical Density (kg/m3) |
200±10 |
||||
|
Shot Content (φ≥0.25mm)(%) |
≤15 |
||||
|
Theoretical Thermal Conductivity (W/m·k) |
0.050-0.060(200°C) |
||||
0.095-0.120(400°C) | |||||
0.160-0.195(600°C) | |||||
Al2O3 (%) |
≥44 |
≥45 |
≥45 |
52-55 |
38-40 |
Al2O3+SiO2 (%) |
≥96 |
≥97 |
≥99 |
≥99 |
- |
ZrO2 (%) |
- |
- |
- |
- |
15-17 |
Al2O3+SiO2+ ZrO2 (%) |
- |
- |
- |
- |
≥99 |
Fe2O3 (%) |
≤1.2 |
≤1.0 |
≤0.2 |
≤0.2 |
≤0.2 |
K2O+Na2O (%) |
≤0.5 |
≤0.5 |
≤0.2 |
≤0.2 |
≤0.2 |
Specification (mm) |
300×300×200,According to your requirements |
||||
Package |
Woven Bag/Carton |
||||
Quality Control System |
ISO9001-2000 ,ISO14001-1996 |
||||
