Specifications
refractory ceramic fiber moduleing temp:1100C
2.density:200kg/m3
3.specification:300*300*200-300mm
ceramic fiber module with anchor system
product Series:
1.1050 Ceramic Fiber Module YXTX-189Z
2.1260 Ceramic Fiber Module YXTX-289Z
3.1260 Ceramic Fiber Module YXTX-389Z
4.1400 Ceramic Fiber Module YXTX-489Z
5.1400 Ceramic Fiber Module YXTX-589Z
Description:
A series of ceramic fiber folded module was processed according the fiber module structure,
size by special machine on the ceramic fiber needle blanket which was corresponding material.
In the course of processing, they should be maintained a certain proportional reduction, to ensure
that compressed to form a integer set without joint between ceramic fiber folded blanket after
ceramic fiber folded module have been built. Owing to the ceramic fiber folded module expand
differently. Ceramic fiber folded module could be fixed to the stud which in the steel board of
industrial furnace by series of anchors.
Characteristic:
Ceramic fiber folded module not only used in furnace, but also brought
following benefit with ended custom:
1. Folded blanket will impact tight with each other in differently way without gaps
after release from packing.
2. Elastically fiber blanket can withstand mechanical force.
3. The elasticity of fiber blanket could make up distortion of furnace casing
and with gaps between modules.
4. Because of the light weight, the decalescence capability is low as the insulation materials.
5. Low thermal conductivity can save much energy
6. Excellent thermal shock resistance capability.
7. Can be betaken immediately as soon as being installed, for there is no need to be dried and
maintained.
8. The Anchor system should be far away from the hot surface of the modules
and kept in the lower temp.
Application:
Furnace lines of various industrial furnace and heating equipment in metallurgy,
machine, construction and material, petrol-chemical and ferrous metal industry.
Technical Index:
Classification Temperature |
1050 |
1260 |
1400 |
||
Code |
YXTX-189Z |
YXTX-289Z |
YXTX-389Z |
TXTX-489Z |
TXTX-589Z |
Shrinkage on Heating (%) |
950°C×24h≤-3 |
1000°C×24h≤-3 |
1100°C×24h≤-3 |
1200°C×24h≤-3 |
1350°C×24h≤-3 |
Theoretical Density (kg/m3) |
200±10 |
||||
|
Shot Content (φ≥0.25mm)(%) |
≤15 |
||||
|
Theoretical Thermal Conductivity (W/m·k) |
0.050-0.060(200°C) |
||||
0.095-0.120(400°C) | |||||
0.160-0.195(600°C) | |||||
Al2O3 (%) |
≥44 |
≥45 |
≥45 |
52-55 |
38-40 |
Al2O3+SiO2 (%) |
≥96 |
≥97 |
≥99 |
≥99 |
- |
ZrO2 (%) |
- |
- |
- |
- |
15-17 |
Al2O3+SiO2+ ZrO2 (%) |
- |
- |
- |
- |
≥99 |
Fe2O3 (%) |
≤1.2 |
≤1.0 |
≤0.2 |
≤0.2 |
≤0.2 |
K2O+Na2O (%) |
≤0.5 |
≤0.5 |
≤0.2 |
≤0.2 |
≤0.2 |
Specification (mm) |
300×300×200,According to your requirements |
||||
Package |
Woven Bag/Carton |
||||
Quality Control System |
ISO9001-2000 ,ISO14001-1996 |
||||
