Help CenterRefractory Insulation Ceramic Fiber Module for Fornace High Quality Ceramic Fiber Module High Pure Ceramic Fiber Module
Related Products
-
Furnace Door Seal Ceramic Fiber Module Expansion Joint Filler Ceramic Fiber Module Industrial Ceramic Fiber ModuleNegotiableMOQ: 10 Pieces -
Furnace Door Seal Ceramic Fiber Module Refractory Ceramic Fiber Module Heat Protection Ceramic Fiber ModuleNegotiableMOQ: 100 Pieces
-
Refractory Fiber Module for Ceramic Shuttle Kiln Aluminum Silicate Wool Module Electric Ceramic Furnace Ceramic Fiber ModuleNegotiableMOQ: 10 Pieces
-
Ceramic Fiber Module Z-block Refractory Thermal Insulation Material for OvenNegotiableMOQ: 100 Pieces
-
Lightweight Ceramic Fiber Module Refractory Module Ceramic Fiber BlockNegotiableMOQ: 100 Pieces
Characteristic:
Ceramic fiber folded module not only used in furnace,but also brought following benefit with ended custom:
1. Folded blanket will impact tight with each other in differently way without gaps after release
from packing.
2. Elastically fiber blanket can withstand mechanical force.
3. The elasticity of fiber blanket could make up distortion of furnace casing and with gaps
between modules.
4. Because of the light weight, the decalescence capability is low as the insulation materials.
5. Low thermal conductivity can save much energy
6. Excellent thermal shock resistance capability.
7. Can be betaken immediately as soon as being installed, for there is no need to be dried and
maintained.
8. The Anchor system should be far away from the hot surface of the modules and kept in the
lower temp.
Application:
Furnace lines of various industrial furnace and heating equipment in metallurgy, machine, construction and material, petrol-chemical and ferrous metal industry
Technical Index:
Classification Temperature |
1050 |
1260 |
1400 |
||
Code |
YXTX-189Z |
YXTX-289ZZ |
YXTX-389Z |
TXTX-489Z |
TXTX-589Z |
Shrinkage on Heating (%) |
950°C×24h ≤-3 |
1000°C×24h ≤-3 |
1100°C×24h ≤-3 |
1200°C×24h ≤-3 |
1350°C×24h ≤-3 |
Theoretical Density (kg/m3) |
200±10 |
||||
|
Shot Content (φ≥0.25mm)(%) |
≤15 |
||||
|
Theoretical Thermal Conductivity (W/m·k) |
0.050-0.060(200°C) |
||||
0.095-0.120(400°C) | |||||
0.160-0.195(600°C) | |||||
Al2O3 (%) |
≥44 |
≥45 |
≥45 |
52-55 |
38-40 |
Al2O3+SiO2 (%) |
≥96 |
≥97 |
≥99 |
≥99 |
- |
ZrO2 (%) |
- |
- |
- |
- |
15-17 |
Al2O3+SiO2+ ZrO2 (%) |
- |
- |
- |
- |
≥99 |
Fe2O3 (%) |
≤1.2 |
≤1.0 |
≤0.2 |
≤0.2 |
≤0.2 |
K2O+Na2O (%) |
≤0.5 |
≤0.5 |
≤0.2 |
≤0.2 |
≤0.2 |
Specification (mm) |
300×300×200,According to your requirements |
||||
Package |
Woven Bag/Carton |
||||
Quality Control System |
ISO9001-2000 ,ISO14001-1996 |
||||
