Home > Chemicals > Inorganic Fiber > Ceramic Fiber > Fire Protection Ceramic Fiber Module

Fire Protection Ceramic Fiber Module

Name: Fire Protection Ceramic Fiber Module
Brand: Yaoxing
SKU: 102719199
Availability: InStock

Fire Protection Ceramic Fiber Module thumbnail-1

Fire Protection Ceramic Fiber Module photo-1

US$ 8 - 10 MOQ: 50 Sets

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Yaoxing

Model Number:

YXTX-389

Contact Supplier Request Quote Chat Now

Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Yaoxing

Model Number YXTX-389

Application heat insulation

Grade HP (High Pure)

Dimensions 300*300*200-300 or according to your requirments

Working Temperature 1100°C

Fiber Diameter 3um

Thermal Conductivity 0.045

Shrinkage (1800℉, 3h) <3%

Specifications

Low heat storage
Excellent corrosion resistance
Faster temperature cycling
Fast and easy installation

Ceramic Fiber Modules
YAO XING modules are made from ceramic fiber blanket stacked with cut edges exposed, and anchor systems to enable quick, easy and efficient installation in most furnace linings. These prefabricated modules are designed to meet the thermal insulation requirements of high temperature furnaces.
Classification Temperature 1050°C ,1260°C, 1400°C,
Density: 200/220kg/m3

Advantages

1. Excellent thermal and physical stability
2. Low thermal conductivity
3. Low heat storage
4. Excellent corrosion resistance
5. Faster temperature cycling

6. Fast and easy installation

Availabilities

300mm x 300mmx 200~300mm (Thickness)

Custom sizes available upon request
Z-Block modules are available upon request,

Applications

1.Oil heaters
2.Reformer
3.Forge furnaces
4.Process heaters
5.Preheating furnaces

6.Crude oil heaters
7.Fume incinerators
8.Tunnel kilns
9.Cracking Furnaces
10.Shuttle kilns
11.Annealing furnaces

Technical Index:

Classification Temperature	1050	1260		1400
Code	YXTX-189	YXTX-289	YXTX-389	TXTX-489	TXTX-589
Shrinkage on Heating (%)	950°C×24h≤-3	1000°C×24h≤-3	1100°C×24h≤-3	1200°C×24h≤-3	1350°C×24h≤-3
Theoretical Density (kg/m3)	200±10
Shot Content (φ≥0.25mm)(%)	≤15
Theoretical Thermal Conductivity (W/m·k)	0.050-0.060(200°C)
	0.095-0.120(400°C)
	0.160-0.195(600°C)
Al2O3 (%)	≥44	≥45	≥45	52-55	38-40
Al2O3+SiO2 (%)	≥96	≥97	≥99	≥99	-
ZrO2 (%)	-	-	-	-	15-17
Al2O3+SiO2+ ZrO2 (%)	-	-	-	-	≥99
Fe2O3 (%)	≤1.2	≤1.0	≤0.2	≤0.2	≤0.2
K2O+Na2O (%)	≤0.5	≤0.5	≤0.2	≤0.2	≤0.2
Specification (mm)	300×300×200,According to your requirements
Package	Woven Bag/Carton
Quality Control System	ISO9001-2000 ,ISO14001-1996
