Home > Products > Horizontal Universal Lathes > CDE6266x2200 economic conventional metal lathe machine
CDE6266x2200 economic conventional metal lathe machine
- 100 Set / Sets per Month
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T Credit Card PayPal
Product Details
Condition: | New | Type: | Horizontal | CNC or Not: | Normal |
Automatic Grade: | Manual | Max. Swing Diameter: | 660mm | Place of Origin: | Liaoning, China |
Brand Name: | DALIAN | Model Number: | CDE6266Ax2200 conventional metal lathe machine | Voltage: | Customer's Requirement |
Power(W): | 5.5kW/7.5kW | Dimension(L*W*H): | 4800x1120x1610mm | Weight: | 2700kgs |
Certification: | ISO9001:2008; GB/T19001:2008; | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CDE6266x2200 conventional metal lathe machine
1. It can machine inner circle, outer circle, and end and head surface, taper surface;
2. Gap lathe can process the deformation parts;
3. Function is including the drilling and reaming;
4. Threads cutting: Metric, inch, diametrical pitch, module thread;
Such conventional metal gap lathe machine has following features:
1. the CDE series lathe can process Steel, cast iron, non-metal material;
2. the precision can reach up to IT7 level;
3. the surface roughness can be up to 1.6 grade;
4. the bed is made of high-grade cast iron,
5. the guide way is super audio frequency quenching.
Specifications | Unit | Parameter |
Max. swing over bed | mm | 660 |
Max. swing over carriage | mm | 430 |
Max. swing over gap | mm | 910 |
Width of guide way | mm | 394 |
Dia. of spindle bore | mm | 52 |
Distance between centers | mm | 3000 |
Taper of center sleeve |
| Morse No.6 |
Spindle speed | rpm | 11~1400/22speeds |
Longitudinal feed | mm/rev | 0.035~2.842 |
Cross feed | mm/rev | 0.009~0.804 |
Metric thread | mm | 0.5~240(66) |
Inch thread | tpi | 80~1/4(49) |
Module thread | mm | 0.25~120(57) |
Diametrical pitch thread | DP | 160-7-16 (50) |
Section of tool shank | mm | 25×25 |
Travel of top slide | mm | 150 |
Max. travel of cross slide | mm | 393 |
Pitch of longitudinal lead screw | mm | 12 |
Travel of tailstock center sleeve | mm | 150 |
Diameter of tailstock center sleeve | mm | 75 |
Taper of tailstock center sleeve | Morse | Morse No.5 |
Main motor power | kW | 7.5kW(50Hz) 5.5kW(60Hz) |
Wooden case/Steel pallet | mm | 4990×1150×1900/ 4800×1120×1610 |
Gross/net weight | kg | 3393/2698 |
