CDE6250 Series Economic Conventional Horizontal Lathe

Name: CDE6250 Series Economic Conventional Horizontal Lathe
Brand: DALIAN
SKU: 102718875
Availability: InStock

US$ 5,953 - 7,498 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 500mm

Place of Origin Liaoning, China

Brand Name DALIAN

Model Number CDE6250A(500x750/1000/1500mm)

Voltage 220V 380V 400V 415V 440V 480V

Power(W) 5.5/7.5kW

Certification ISO9001:2008; GB/T19001:2008

After-sales Service Provided Engineers available to service machinery overseas

CDE6250 Conventional Lathe

Machine Features

Specifications	Unit	CDE6250Ax750	CDE6250Ax1000	CDE6250Ax1500
Max. swing over bed	mm	500	500	500
Max. swing over carriage	mm	290	290	290
Max. swing over gap	mm	760	760	760
Width of guide way	mm	394	394	394
Dia. of spindle bore	mm	52	52	52
Distance between centers	mm	750	1000	1500
Taper of center sleeve		Morse No.6	Morse No.6	Morse No.6
Spindle speed	rpm	11~1400/22speeds	11~1400/22speeds	11~1400/22speeds
Longitudinal feed	mm/rev	0.035-2.842	0.035-2.842	0.035-2.842
Cross feed	mm/rev	0.009-0.804	0.009-0.804	0.009-0.804
Metric thread	mm	0.5-240(66)	0.5-240(66)	0.5-240(66)
Inch thread	tpi	80-1/4(49)	80-1/4(49)	80-1/4(49)
Module thread	mm	0.25-120(57)	0.25-120(57)	0.25-120(57)
Diametrical pitch thread	DP	160-7-16 (50)	160-7-16(50)	160-7-16(50)
Section of tool shank	mm	25×25	25×25	25×25
Travel of top slide	mm	150	150	150
Max. travel of cross slide	mm	348	348	348
Pitch of longitudinal lead screw	mm	12	12	12
Travel of tailstock center sleeve	mm	150	150	150
Diameter of tailstock center sleeve	mm	75	75	75
Taper of tailstock center sleeve	Morse	Morse No.5	Morse No.5	Morse No.5
Main motor power	kW	7.5kW(50Hz)/5.5kW(60Hz)	7.5kW(50Hz)/5.5kW(60Hz)	7.5kW(50Hz)/5.5kW(60Hz)
Wooden case/Steel pallet	mm	2740×1150×1900 2580×1120×1610	2950×1150×1900 2830×1120×1610	3450×1150×1900 3330×1120×1610
Gross/net weight	kg	2665/1970	2765/2070	2855/2120
