CK5116SSD cnc vertical turning lathe machine
Such CK5116SSD cnc vertical turning lathe machine has following features:
1. It has a Vertical tool rest, which the Maximum machining diameter is 1600 mm, the Maximum working height is 1600 mm.
2. The gears is setted in the system. 40 Cr is used in all gear grinding gear ,which has high rotation accuracy, low noise characteristics.
3. This machine is suitable for high speed steel tools and carbide cutting tool machining all kinds of non-ferrous metal, black metal and part of the non-metallic materials.
4. CE Standard and CE Certificate;
Specifications |
Unit |
Parameter |
Max. turning diameter |
mm |
1600 |
Worktable diameter |
mm |
1400 |
Max. turning height |
mm |
1600 |
Maximum workpiece weight |
t |
8 |
Table speed range |
r/min |
6.3~200 |
Table speed series |
Grade |
II stepless |
Maximum table torque |
Kn/m |
25 |
Tool post feed rate |
º |
stepless |
Degree of limit of vertical tool rest |
|
30 |
Maximum cutting force of vertical tool rest |
KN |
25 |
RAM horizontal travel |
mm |
915 |
RAM vertical travel |
mm |
800 |
Ram movement |
mm |
850 |
Rest fast moving speed |
mm/min |
3000 |
Beam Lift Speed |
mm/min |
580 |
Tool rod section size (length x width) |
mm |
30×40 |
Main motor power |
kW |
37 |
Nc axes |
|
X, Z Biaxial linkage |
Location accuracy |
mm |
0.03 |
Repositioning resolution |
mm |
0.015 |
Processing dimensional accuracy |
|
IT 7 |
Machine weight (about) |
T |
16 |
Numerical control system |
|
SIEMENS 828D |
Controlled Axes |
|
2 Axle |
Compounding axis number |
|
2 Axle |
Nc axes |
|
X, Z |
Interpolation |
|
Straight line and arc |
Compensation |
|
With reverse clearance, pitch error compensation and tool wear compensation and nose radius compensation |
Coordinate setting |
|
Workpiece coordinate setting |
Displayer |
|
10.4"LCD Color display in English |
Multiplying power |
|
Fast rate |
Controller |
|
Built-inprogrammablecontroller |
Programme |
|
Drawing size programming directly |
Feed |
|
With a manual electronic hand wheel feed (hand pulse generator) |
Alarm |
|
Machine tools and operating all kinds of alarm display |
Port |
|
External computer interface RS - 232 - c, CF card and Ethernet front-end ports |
Real time copying |
|
Figure trace real-time display |
Manual feed |
|
Hand pulser X, Z axis |
No |
Name |
Size |
Quantity |
1 |
Technical documents |
|
1 Set |
2 |
Chuck jaw |
5116D01001 |
4 Sets |
3 |
Chuck jaw screw |
|
16 Sets |
4 |
Tool chuck |
|
1 Set |
5 |
Adjustable parallels |
|
8 pieces |
6 |
Ground screw |
M24x500 |
8 Pieces |
7 |
Hex nut |
M24 |
8 Pieces |
8 |
Gasket |
24 |
8 Pieces |
9 |
Chuck wrench |
24 |
1 Set |
10 |
Hexagon wrench |
32 |
1 Set |
11 |
Square sleeve spanner |
22 |
1 set |
