Large Spindle Bore Lathe- Spindle Hole 200mm

Name: Large Spindle Bore Lathe- Spindle Hole 200mm
Brand: Dalian
SKU: 102718595
Availability: InStock

US$ 10,500 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 800mm

Place of Origin Liaoning, China

Brand Name Dalian

Model Number LFM6163/6180, LFM6163/6180

After-sales Service Provided Engineers available to service machinery overseas

Large Spindle Lathe sheet

Specifications	Unit	LFM6163	LFM6180
Max swing dia.over bed	mm	630	800
Max swing dia. over tool post	mm	345	550
Distance between two center	mm	750 1500 2000 3000 4000 6000 7000 8000	750 1500 2000 3000 4000 6000 7000 8000
Diameter range of pipe thread	mm		50~200
Width of bed	mm		490
Spindle bore	mm	Φ200	Φ200
Range of spindle speeds	rpm	14~750	36~480
Steps of spindle speed		18 steps	12 steps
Range/kinds of metric threads	mm	1~224mm/52kinds	1~14mm/24kinds
Range/kinds of inch threads		2~28T.P.I/40kinds	2~28T.P.I/40kinds
Range/kinds of module threads	mm	0.25~56mm/41kinds	0.25~56/41kinds
Range /kinds of diametrical pitch thread		1~112T.P.I/38kinds	1~112T.P.I/38kinds
Pitch of lead screw	mm	12.7	12.7
Max.longitudinal travel of saddle	mm		1310
Power of main motor	kW	11	11
Overall dimensions(LxWxH)	mm	5000x1449x1393	5157x1449x1393
Net weight	kg	5000	5500
