Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > Bench Lathe LFM6132A 1 Phase/3 Phase

Bench Lathe LFM6132A 1 Phase/3 Phase

Name: Bench Lathe LFM6132A 1 Phase/3 Phase
Brand: Dalian
SKU: 102718593
Availability: InStock

Bench Lathe LFM6132A 1 Phase/3 Phase thumbnail-1

Bench Lathe LFM6132A 1 Phase/3 Phase photo-1

US$ 2,500 - 5,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 320mm

Place of Origin Liaoning, China

Brand Name Dalian

Model Number LFM6132A

After-sales Service Provided Engineers available to service machinery overseas

Bench lathe Parameter

It can machine inner circle, outer circle, and end and head surface, taper surface. Gap lathe can process the deformation parts. Function is including the drilling and reaming. Metric, inch, diametrical pitch, module thread.The bed is made of high-grade cast iron The bed is undergoing surface quenching, the hardness can be HRC50.

Specifications	Unit	LFM6132A
Max swing diameter over bed	mm	330
Max swing diameter over table	mm	185
Distance between centers	mm	610
Taper of spindle bore		MT5
Spindle bore	mm	40
Spindle speed/grade	rpm	180~1930/8
Chuck specification		KZ11-160
Tool shank	mm	20x20
Longitudinal travel	mm	600
Cross travel	mm	170
Small toolpost travel	mm	85
Longitudinal feed/grade	mm	0.1~0.4/3
Metric pitch/grade	mm	0.5~3mm/10
Inch pitch/grade		8~48.T.P.I/14
Tailstock taper		MT3
Power of main motor		One phsae, 220V/1.5kW 3 phase, 380V/1.5kW
Net weight/ Gross weight	kg	530/610
Overall dimensions of machine	mm	1670x790x1480
