Help CenterAluminosilicate Board Ceramic Fiber Board Sound Insulation Materials for Car
Related Products
-
10mm Alumina Silicate BoardNegotiableMOQ: 1 Metric Ton -
Ceramic Firing Kiln Board Ceramic Fiber Board Heat Insulation Ceramic Fiber BoardNegotiableMOQ: 100 Parcels
-
Thermal Insulators Board for CarsNegotiableMOQ: 100 Cartons
-
Thermal Insulators Board 300kg/m3 Ceramic Fiber Board Heat Insulation Ceramic Fiber BoardNegotiableMOQ: 100 Cartons
-
Refractory Kiln Cars Baord Ceramic Kilns Ceramic Fiber Board Vacuum Insulation PanelsNegotiableMOQ: 100 Pieces
Technical Index
Type | Common | Standard | High Pure | High Aluminum | High Zirconium | |||
Code | YXTX-134 | YXTX-234 | YXTX-334 | YXTX-434 | YXTX-534 | |||
Classification Temperature | 1050 | 1260 | 1260 | 1400 | 1400 | |||
Shrinkage on Heating (%) | 950°C×24h ≤-3 | 1000°C×24h ≤-3 | 1100°C×24h ≤-3 | 1200°C×24h ≤-3 | 1350°C×24h ≤-3 | |||
Theoretical Thermal Conductivity (W/m·k)(128kg/m3) | (200°Caverage) (400°Caverage) (600°Caverage) | 0.045-0.060 0.085-0.110 0.152-0.20 | 0.052-0.070 0.095-0.120 0.164-0.210 | |||||
Theoretical Density (kg/m3) | 220-320 | 220-400 | 220-450 | 220-500 | 220-500 | |||
Specification (mm) | 1200/1000/900/600×1000/600/400×10/20//30/40/50 According to your requirements | |||||||
Tensile Strength (25mm thick) MPa | 0.5 | |||||||
AL2O3 (%) | ≥44 | ≥45 | ≥45 | 52~55 | 38~40 | |||
ZrO2 (%) | - | 15~17 | ||||||
AL2O3+SiO2 (%) | ≥96 | ≥97 | ≥99 | ≥99 | — | |||
AL2O3+SiO2+ZrO2 (%) | — | — | — | — | ≥99 | |||
Fe2O3 (%) | ≤1.2 | ≤1.0 | ≤0.2 | ≤0.2 | ≤0.2 | |||
K2O+Na2O (%) | ≤0.5 | ≤0.5 | ≤0.2 | ≤0.2 | ≤0.2 | |||
Package | Plastic Bag Inside, Carton Box Outside | |||||||
Quality Control System | ISO9001-2000, ISO14001-1996 | |||||||
Description:
1.YAOXING 1050/1260 Ceramic Fiber Board was processed by the advanced production line,
which was adopted the full automatic control and the continuous- processing method.
2.YAOXING 1050/1260 Ceramic Fiber Board have many typical characteristics,
such as exact measurement,excellent toughness,
excellent heat preservation and can be cut discretionally
3.The processing work is much advanced, which totally
avoid the long production cycle and the low production capacity.
4.YAOXING 1050/1260 Ceramic Fiber Board is divided in different series by the temperature,
can be widely used as the back lining of industrial furnace
and the hot surface of the low temperature furnace.
It is one of the guarantees of reaching the energy conservation and the high quality.
Characteristic:
1.Low Heat Storage
2.low thermal conductivity
3.Excellent compressive strength
4.Not fragile materials
5.Excellent flexibility
6.Exact measurement
7.Excellent flatness
8.Homogeneous structure
9.Excellent machine-processed capability
10.Easily fixing specialty
11.Processed continuously,the fibers interweave shapely
12.Excellent stability
13.Excellent chemical stability and thermal shock resistance
