VDF1800 sliding guide way cnc vertical machining center with CE

FOB Price

USD $115,132 - $178,060 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Type:	Vertical	Place of Origin:	Liaoning, China
Brand Name:	DALIAN	Model Number:	VDF1800 cnc vertical machining center	Voltage:	220V 380V 400V 415V 440V 480V
Power(W):	11/15kW	Dimension(LWH):	5530x3895x3100mm	Weight:	14500kgs
Certification:	CE Certificate; ISO9001:2008; GB/T19001:2008	Warranty:	12 months	After-sales Service Provided:	Engineers available to service machinery overseas

VDF1800 sliding way cnc vertical machining center

Machine Featurers:

1. With CE Certificate;

2. National Inspection-free products

3. Highly rigid and stable machine structure;

4. High precision Box Ways on all three-axis;

5. High precision spindle and High spindle speed: 8000~10000rpm;

6. Fast and reliable tool changing mechanism;

7. Cooling system;

8. Multi-functional CNC control system, such as: FANUC, SIEMENS, FAGOR, REXROTH, MITSUBISHI, etc;

Real Photos

New Design

Main Technical Data

Specifications	Unit	Parameter
Table ( L× W)	mm	2000×800
T-slot (Numbers × Width × Distance) (b/t slots)	mm	6×18×125
Table load Max	kg	2500
Distance from spindle center line to column guide way surface	mm	850
Distance from spindle nose to table upper surface	mm	180~942
X/Y/Z travel	mm	1850/800/762
X/Y/Z guide way type		Sliding guide way Y-axis 4 rails
X/Y/Z rapid traverse speed	m/min	15/15/12
Feed rate	mm/min	1~6000
Positioning accuracy	mm	X:0.030 Y/Z:0.020
Repeat positioning accuracy	mm	X:0.013 Y/Z:0.008
X/Y/Z servo motor power	Nm	22/22/22
Spindle motor power	kW	11/15 wide range motor
Spindle speed range	r/min	45~6000
Spindle taper		#50 (7/24)
Tool magazine capacity/Type		24/swing arm
Tool adaptor type		BT50
Max. Tool weight	kg	15
Max. Tool diameter / length	mm	110/350 swingarm
Time of tool change (T-T)	sec	3.5
Air pressure requirement	MPa	0.6
Power requirement	kW	40
Overall dimension (L × W × H)		5160×3480×3120
Net weight	kg	14500
Machine covers an area of size	mm	5530×3895
