Home > Manufacturing & Processing Machinery > Machine Tools > Boring Machine > Manual Horizontal Boring and Milling Machine

Manual Horizontal Boring and Milling Machine

Name: Manual Horizontal Boring and Milling Machine
Brand: DALIAN
SKU: 102713031
Availability: InStock

Manual Horizontal Boring and Milling Machine thumbnail-1

Manual Horizontal Boring and Milling Machine photo-1

US$ 58,560 - 145,878 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

Normal

Place of Origin:

Liaoning, China

Contact Supplier Request Quote Chat Now

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not Normal

Place of Origin Liaoning, China

Brand Name DALIAN

Model Number TPX6111 TPX6111A TPX6111A/2 TPX6113 TPX6113A TPX6113A/2 TPX6113A/3

Voltage 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz

Certification CE Certificate; ISO9001:2008; GB/T19001:2008

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Horizontal Manual Type;
Spindle bore diameter: 110/130mm;
With DRO for X/Z axies;

Boring and Milling Machine Boring and Milling Machine

to: export(at)

Boring Machine:

1. TPX61 series digital readout horizontal boring and milling machines are universal machine tools which can be adapted to machine casting, steel, and nonferrous word- places.

2. Operations include drilling, hole enlarging, boring, reaming, plane milling, spot facing, threading, and other machining processes.

3. The faceplate slide can be fed radically, which enables the machine to bore large size holes, turning outside diameters, and grooving.

4. This series of machine can be used in the industries of energy, metallurgy, mining, machinery, military, etc it is a reliable choice for machining box- type part.

5. Spindle of better rigidity, stronger cutting force, higher efficiency.

7. Optical sensor available for higher table locating accuracy

8. DRO available for both X and Z axes;

9. Automatic tool loading and unloading available as optional with spindle of ISO7:24 at 50 taper;

Specifications	Unit	TPX6111	TPX6111A	TPX6111A/2	TPX6113	TPX6113A	TPX6113A/2	TPX6113A/3
Spindle bore diameter	mm	Φ110	Φ110	Φ110	Φ130	Φ130	Φ130	Φ130
Spindle taper	MT	6	6	6	80#	80#	80#	80#
Max, spindle torque	Nm	1225	1225	1225	3136	3136	3136	3136
Max. spindle axial thrust	N	12250	12250	12250	31360	31360	31360	31360
Steps of spindle speed		22	22	22	24	24	24	24
Range of spindle speed	r/min	8~1000	8~1000	8~1000	4~800	4~800	4~800	4~800
Power of main motor	kW	7.5	7.5	7.5	15	15	15	15
Max. facing head torque	Nm	1960	1960	1960	4900	4900	4900	4900
Facing head diameter	mm	Φ600	Φ600	Φ600	Φ750	Φ750	Φ750	Φ750
Range of facing head speed	r/min	4~200	4~200	4~200	2.5~125	2.5~125	2.5~125	2.5~125
Speed step of facing head	steps	18	18	19	18	18	18	18
Table size	mm	1140 x1000	1140 x1000	1300 x1250	1600 x1400	1600 x1400	1800 x1600	1800 x1600
Max. permissible load on table	kg	2500	2500	2500	8000	8000	8000	8000
T- slot (width x No.)	mm	22x 7	22x 7	22 x 7	28 x 9	28 x 9	28 x 9	28 x 9
X- axis travel	mm	1000	1350	1600	1600	2000	2000	3000
Y - axis travel	mm	1000	1000	1300	1500	1800	2000	2000
Z - axis travel	mm	1000	1000	1000	1500	1500/2000(Without Rear Column)	1500/2000(Without Rear Column)	1500/2000(Without Rear Column)
W- axis travel (Spindle travel)	mm	600	600	600	900	900	900	900
U - axis travel (facing head spindle travel)	mm	180	180	180	250	250	250	250
B - axis work table rotary	°	360	360	360	360	360	360	360
Min. distance between spindle center and table surface	mm	0	0	0	0	0	0	0
Rapid travel (X/Y/Z)	mm/min	2500	2500	2500	2500	2500	2500	2500
Range of feed (X/Y/Z)	mm/rev	0.04~6	0.04~6	0.04~6	0.04~6	0.04~6	0.04~6	0.04~6
Precision of measurement accuracy (X/Y/Z)	mm	0.01	0.01	0.01	0.01	0.01	0.01	0.01
Overall dimensions (LWH)	mm	4910x2560x2850	4910x2560x2850	4910x2560x2850	6995x3730x3535	6995x3730x3535	7050x4030x950	7050x4030x950
Weight of machine	kg	12000	13500	14800	24500	28500	32000	32500
