Genew KDW660/12B Anti-Explosion & Intrinsic- Safety DC Supply INTEGRATED MINING SOLUTION
1. The KDW660/12B Anti-Explosion & Intrinsic-Safety DC Supply uses high-performance integrated circuits to provide high DC current voltage output.
2. The output power has over-current and short circuit protection. The backup power source uses small size and high-capacity, rechargeable NiCad battery pack.
On power outage, the backup source can last for more than 2 hours.
Input Voltage Requirements: 660VAC/127VAC (75% - 110% )
Output Voltage: 12VDC, 1A
Open-Circuit Voltage: 11.98VDC
Short-Circuit Current: 0.52A/0.62A
Over-Current Protection Threshold: 1.22A/1.22A
Random Offset Peak2Peak Value: ≤ 250mV
Line Regulation (%): 0.03/0.03
Load Effect: 2.20/2.64
Output Voltage Deviation (%): 2.33/2.72
Backup Battery Parameters:
a)Backup battery pack: 15 section 3.0Ah, 1.2V NiCad battery pack
b)Conversion Time: ≤ 0.1s
c)Standby Time: ≥ 2h
d)Maximum Charging Voltage: 20.53VDC
e)Discharge Termination Voltage: 14.25VDC
Packaging:
1. All products will be packed in carton, so the product can get effective protection to avoid damage.
2. Packaging according to customer requirement
Shipping:
1. We shipping via DHL / FedEx / TNT etc for samll orders. Yow can get your packages in about 3-5 days all over the world.
2. For big order, we will arrange Air cargo for your shipment, so it will be much cheaper than DHL, UPS etc.
3. You can choose your own shipping agent, we will provide good cooperation for it.
1,We can provide detail documents and remote help for device installation and configuration.
2,Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3,Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned goods must keep original state and it’s accessories are complete.
