small concrete interlocking brick making machine,paver block making machine
- 1000 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
- China pe200x300 smallest jaw crusher
- Popular compound pendulum jaw crusher price
- 2016 china products stone coated steel roofing tile ,shingle steel roof tile
- 2016 china products lightweight roof tile,blue glazed roof tile
- colored metal roofing prices,sand coated metal roofing tiles
- roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Paving Block Making Machine | Brick Raw Material: | Other, sand,cement,fly ash,etc |
Processing: | Brick Molding Machine | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | 9600pcs/day | Place of Origin: | Henan, China | Brand Name: | Yingfeng |
Model Number: | 400 | Voltage: | 220-480V | Power: | 7.5KW |
Dimension(L*W*H): | 1750*1700*2000mm | Certification: | ISO9001 | Warranty: | 2 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Description of our paver block making machine
The Paver block making machine of model 400/500/600 are produced with new technology. This product is very popular with its advantages of energy saving,less noise and less pollution.By changing the brick moulds,it can not only produce various kinds of paver blocks but also solid bricks, curb stones and so on.Hydraulic machinery is very popular because of the enormous amount of power that can be transferred through small tubes and flexible hoses, and the wide variety of equipment that makes use of this technology.
Technical Parameters of 400 Paver Block Making Machine:
Model | 400 Paver block machine |
Overall dimension | 1750*1700*2000mm |
Rated power | 7.5KW |
Max. pressure | 200T |
Cycle time | 30s |
Mold box size | 400X400mm |
Total weight | 1500kg |
Capacity of 400 Paver block making machine | ||||
Product | Product Size | capacity/mould | cycle | capacity/8 hours |
Standard brick | 240x115x53mm | 3pcs/mould | 30s | 9600 pcs/day |
Holland brick | 200x100x60mm | 8pcs/mould | 30s | 14400 pcs/day |
Paving brick | 250x250x40mm | 4pcs/mould | 30s | 5600 pcs/day |
Technical Parameters of 500 Paver Block Making Machine:
Model | 500 Paver block machine |
Overall dimension | 2000*2000*2200mm |
Rated power | 16.5KW |
Hydraulic pressure | 230T |
Cycle time | 30s |
Moulding Size | 500X400mm |
Total weight | 5000kg |
Capacity of 500 Paver block making machine | ||||
Product | Product Size | capacity/mould | cycle | capacity/8 hours |
Standard brick | 240x115x53mm | 8pcs/mould | 30s | 10000 pcs/day |
Holland brick | 200x100x60mm | 8pcs/mould | 30s | 8000 pcs/day |
Paving brick | 250x250x40mm | 4pcs/mould | 30s | 5600 pcs/day |
Technical Parameters of 600 Paver Block Making Machine:
Model | 600 Paver block machine |
Overall dimension | 2200*2000*2200mm |
Rated power | 20KW |
Hydraulic pressure | 360T |
Cycle time | 30s |
Moulding Size | 600X500mm |
Total weight | 5000kg |
Capacity of 600 Paver block making machine | ||||
Product | Product Size | capacity/mould | cycle | capacity/8 hours |
Standard brick | 240x115x53mm | 10pcs/mould | 30s | 12000 pcs/day |
Holland brick | 200x100x60mm | 12pcs/mould | 30s | 10000 pcs/day |
Paving brick | 250x250x40mm | 4pcs/mould | 30s | 5600 pcs/day |
Features of this hydraulic paver making machine
1,Hydraulic paver block making machine can be used widely
2,Low investment,good profit,repays quickly,it is the best for the new investor on brick machines
3,Good quality,and wide variety.
Kinds of paver blocks
