Garbage truck Howo JHL5250ZYS 16CBM
large compression force
without secondary pollution
high automatic degrees
quick loading
Properties and applications:
Compressed garbage truck is produced by using Germany technology, and has outstanding technical advantage. The product has high system pressure, large compression force, high volume rate and large loading capacity, can make loading capacity increase 5-7 times, has high automatic
degrees, quick loading speed, convenient, safe and reliable operation, and hasn’ t secondary pollution. The product is suitable for collection and transportation of urban living garbage, industrial and commercial non-toxic garbage. New developed compartment removable compressed
garbage truck uses compartment and truck separation, is equipped with several compartments for one truck, and can be used as small garbage transfer station.
No. | Item | Unit | Value |
1 | Vehicle Model |
| JHL5162ZYS |
2 | Chassis model |
| ZZ3161M4311C1 |
3 | Drive type |
| 6*4 |
4 | Engine power | Kw | 196,198,213,221 |
5 | Overall dimension of truck (L × W × H) | mm | 7500*2490*3250 |
6 | Rated payload | Kg | 10330 ,12000 |
7 | Tank capacity | M3 | 16 |
8 | Loading capacity of collection tank | M3 | 2 |
9 | Wheelbase | mm | 3225+1350 |
10 | Tread(front/rear) | mm | 2022/1830 |
11 | Cycle time for garbage loading | S | ≤ 20 |
12 | System working pressure | MPa | 21 |
13 | Cycle time for garbage unloading | s | ≤ 45 |
14 | Max. pushing force for garbage | kN | 150 |
15 | Compression force for garbage loading | kN | 400 |
