sunlight readable 128x128 dots matrix lcd module display support serial paralell interface with led backlight
- 30000 Piece / Pieces per Month
- Shenzhen Port
- Credit Card
- Digital thermometer hygrometer used for travelling weather station pocket type
- Wireless Atomic Table Clock, Thermometer/Display In/Out Temperature, Blue/Green Backlight Selectable
- Weather Station Clock with Forecast/Desk/Digital Clock with in/Outdoor Temperature and Humidity
- Wired Weather Station/Desk/Digital Clock with In/Outdoor Temperature Display
- MAX / MIN Temperature And Humidity Automatic Memory Digital Thermometer Hygrometer
- Atomic Projection Desk Clock with Indoor Temperature and Big Character Display
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Caijing | Model Number: | CM128128-6FLWAA |
Type: | COB |
Product Description
sunlight readable 128x128 dots matrix lcd module display support serial paralell interface with led backlight
Model number: CM128128-6FLWA
DOT matrix: 128x128 dots
Size: 72.1*65*9mm
V. A: 48*48mm
Drive method: 1/128 duty, 1/12 bias
View angle: 6: 00
Display: FSTN
Voltage: 3V
Controller: ST7541
TOP: -20-70°C
TST: -30-80°C
Our factory pass ISO9001 and all products can pass CE,ROHS,SGS.
14 year's design,manufacture and sales experience
300+ models available,custom orders welcome
exporting to 100+ countries
Free 1-year maintance
Free samples are available for some styles
About graphical lcd module ,we have 120x32 dots matrix lcd module ,122x32 graphical lcd module,128x32 stn lcd display module ,128x64 monochrome lcd module,128x128 lcd display module,160x128 dots matrix lcd display,160x160 stn lcd,
192x64 graphical lcd display module,240x64 lcd,240x128,240x160 and 320x240 lcd module display .
Display Content | Product No. | Outline size(mm) | V.A(mm) | Dot size(mm) | Controller | Supply Voltage | Interface |
120x32 | CM12032-1 | 98×50×14 | 76×26 | 0.55×0.6 | 1520 | 5V/3V | parallel |
122x32 | CM12232-1 | 84×44×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-4 | 67.2×27.2×8.7 | 54.8×18.8 | 0.36×0.41 | 1520 | 5V | parallel |
122x32 | CM12232-5 | 76.5×29×7 | 60.5×20.5 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-7 | 76×32.5×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-10 | 87×29×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-11 | 80.9×29×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-12 | 93×29.3×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-13 | 84×44×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-17 | 66×36×13 | 60×18 | 0.36×0.41 | 1520 | 5V | parallel |
122x32 | CM12232-18 | 84×44×13 | 60×18 | 0.36×0.41 | 1520 | 5V | parallel |
122x32 | CM12232-20 | 84×44×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-21 | 84×44×13 | 60×18 | 0.36×0.41 | 1520 | 5V/3V | parallel |
122x32 | CM12232-26 | 65.4×28.8×5.5 | 54.8×18.3 | 0.36×0.41 | 1520 | 5V | parallel |
122x32 | CM12232-27 | 75.9×31.6×10 | 59.1×16.7 | 0.44×0.42 | ST7565R | 3V | serial/parallel |
128x32 | CM12832-1 | 110×65×14 | 76×25 | 0.52×0.52 | KS0108 | 5V/3V | parallel |
128x32 | CM12832-3 | 110×65×14 | 76×25 | 0.52×0.52 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-1 | 113×65×12.5 | 73.5×39 | 0.458×0.458 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-2 | 93×70×14 | 70.8×38.8 | 0.48×0.48 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-3 | 78×70×12 | 62×44 | 0.39×0.55 | T6963C | 5V/3V | parallel |
128x64 | CM12864-5 | 106×69×12 | 62×44 | 0.39×0.55 | T6963C | 5V/3V | parallel |
128x64 | CM12864-6 | 106×69×12 | 62×44 | 0.39×0.55 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-7 | 107×85×9.5 | 88×60 | 0.6×0.8 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-8 | 78×70×12 | 62×44 | 0.39×0.55 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-10 | 78×70×12 | 62×44 | 0.39×0.55 | T6963C | 5V/3V | parallel |
128x64 | CM12864-11 | 93×70×13 | 73×39 | 0.48×0.48 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-16 | 54×50×6.5 | 43.5×29 | 0.28×0.35 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-17 | 86×61×13.2 | 70.6×38.8 | 0.48×0.48 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-18 | 75×52×12 | 60×32.6 | 0.4×0.4 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-26 | 78×70×12 | 62×44 | 0.39×0.55 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-28 | 93×70×14 | 70.8×38.8 | 0.48×0.48 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-30 | 93×70×13 | 73×39 | 0.48×0.48 | KS0108 | 5V/3V | parallel |
128x64 | CM12864-31 | 54×50×7.5 | 40.5×28.8 | 0.29×0.36 | IST3004 | 3V | serial/parallel |
128x64 | CM12864-32 | 93×70×10.2 | 70.5×38.6 | 0.48×0.48 | ST7565P | 3V | serial/parallel |
128x128 | CM128128-1 | 106×92×14 | 73×73 | 0.49×0.49 | T6963C | 5V | serial/parallel |
128x128 | CM128128-4 | 106×92×14 | 73×73 | 0.49×0.49 | T6963C | 5V | serial/parallel |
128x128 | CM128128-6 | 72.1×65×8.3 | 48×48 | 0.33×0.33 | ST7541 | 3V | parallel |
128x128 | CM128128-8 | 50.0×45.8×7.7 | 31×30 | 0.19×0.19 | ST7541 | 3V | serial/parallel |
160x128 | CM16064-1 | 87×60×12.5 | 61.5×26 | 0.33×0.33 | T6963C | 5V/3V | parallel |
160x128 | CM160128-2 | 129×102×12 | 101×82 | 0.54×0.54 | T6963C | 5V/3V | serial/parallel |
160x160 | CM160160-1 | 67×63×7.5 | 46×46 | 0.245×0.245 | 320A | 3V | parallel |
160x160 | CM160160-3 | 77×73.5×7.8 | 58×58 | 0.32×0.32 | UC1698 | 3V | parallel |
192x64 | CM19264-1 | 130×65×12.2 | 104×39 | 0.458×0.458 | KS0108 | 5V/3V | parallel |
192x64 | CM19264-4 | 120×62×12.2 | 104×39 | 0.458×0.458 | KS0108 | 5V/3V | parallel |
192x64 | CM19264-6 | 100×60×13 | 84×31 | 0.36×0.36 | KS0108 | 5V/3V | parallel |
To be continue --------- |
