Electric Induction Melting Furnace:
1. Turn on and turn off the smelter easily, and power failure will not affect the service life of electric furnace.
2. Adopt constant power to control the circuit, maintain constant power while melting, and keep faster melting rate.
3. Set up over voltage, over current and water deficient protector, and run safely.
4. The motherboard adopts CAD technology, integrated circuit board, low-fault-rate, easy-manipulating, effortless maintenance.
5. Zero voltage starts up softly, high initial power, don´t impact on the electric network.
6. Apply to melting ferrous metal and non-ferrous metal like copper, aluminum, zinc, steel, iron, stainless steel etc..
Technical Parameter:
|
model |
rated capacitykg |
input voltageV |
rated powerkw |
rated frequencyHz |
melt timemin/stove |
consume electricity (kw.h/t) |
consume water (M³/h) |
matched transformer (KVA) |
GW-0.15 |
150 |
380 |
100 |
1000 |
85 |
800 |
3 |
150 |
GW-025 |
250 |
380 |
160 |
1000 |
85 |
800 |
3 |
180 |
GW-0.5 |
500 |
380 |
250 |
1000 |
80 |
750 |
5 |
250 |
GW-1.0 |
1000 |
380 |
500 |
1000 |
75 |
750 |
8 |
500 |
GW-1.5 |
1500 |
380 |
750 |
1000 |
75 |
720 |
10 |
800 |
GW-2.0 |
2000 |
380/660 |
1000 |
500 |
75 |
700 |
12 |
1000 |
GW-3.0 |
3000 |
660 |
1500 |
500 |
75 |
700 |
16 |
1500 |
