Stainless steel melting furnace
Machine Feaure:
1. Energy-saving: Due to melting faster, heating-loss dropped significantly, compared with the same capacity of the ordinary smelter, energy-saving1/3.
2. High-service-life of furnace: Due to short-time of single-melting, the time of high-temperature molten steel washing against the furnace wall is short, so the average service life of this smelter is 2 or 3 times longer than the ordinary smelter.
3. Less-element-burning: Short-time melting reduce the loss rate of the effective alloy elements, burning loss rate of the element is 20% - 60% of the general smelter, then ensure the quality of the alloy.
4. fast-replacement-furnace: Apply to the technology of a water-cooled manual switch, switching from one furnace to another only needs a few seconds.
Can equip pure water closed power source cooling system and hydraulic pressure overturning system.
5. Can equip entirety closed pure water cooling system.
Intermediate frequency melting furnace andIntermediate frequency rapid melting furnace main
Technical Parameter:
model |
rated capacitykg |
input voltageV |
rated powerkw |
rated frequencyHz |
melt timemin/stove |
consume electricity (kw.h/t) |
consume water (M³/h) |
match transformer (KVA) |
KGW-0.05 |
50 |
380 |
125 |
2500 |
16 |
680 |
3 |
150 |
KGW-0.1 |
100 |
380 |
175 |
2500 |
22 |
650 |
3 |
180 |
KGW-0.15 |
150 |
380 |
225 |
2500 |
25 |
630 |
5 |
250 |
KGW-0.25 |
250 |
380 |
325 |
2500 |
28 |
610 |
10 |
350 |
Any further question, pls contact me
Site pictures:
1, One year warranty service.
2, Sending professional engineer to installation,
debugging and training.
3, Provide video for teaching, installation instruction, and other
relevant technical documents.
4, We have more than 20 years experienced casting engineer to
solve any your problem.
