Agriculture Plastic BLOWN FILM EXTRUSION MACHINE

Agriculture Plastic BLOWN FILM EXTRUSION MACHINE photo-1
Agriculture Plastic BLOWN FILM EXTRUSION MACHINE photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Film
Plastic Processed PE
Blow Moulding Type Extrusion Blow Moulding
Automatic Yes
Place of Origin Zhejiang, China
Brand Name YUNFENG
Model Number YF-FE
Voltage 220v 380v 440v
Power(W) 37-90kw
Dimension(L*W*H) 6..8*2.6*6.5
Weight 2T 2.5T 3T
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas



YF-FE Color Master Lab Extruder

Agriculture Plastic BLOWN FILM EXTRUSION MACHINE

1.Uses and Features:

It is fit to puff high density and low density polyethylene industry film, farm-oriented mulch film. The cylinder and  the screw stems of the  extruder  are  made of  high-quality  alloy  steel  with optimum hardness  and  strong  corrosion  resistance after nitrogen  treatment and  precision  finishing. It is   double rolling  and  account  the  meter  automatically.

 Agriculture Plastic BLOWN FILM EXTRUSION MACHINE



  2.Main Technical Variables:

MODEL

SJ-C80

SJ-C90

SJ-C100

SJ-C120

SUITABLE MATERIAL

LDPE LLDPE

FILM WIDTH(mm)

800-1500

1000-2000

1500-2500

1800-3300

FILM THICKNESS (mm)

0.015-0.15

0.015-0.15

0.015-0.15

0.015-0.15

MAX.EXTRUSION OUTPUT

150kg/hr

280kg/hr

350kg/hr

450kg/hr

EXTRUDER

SCREW DIAMETER(mm)

Φ80

Φ90

Φ100

Φ120

SCREW L/D LENGTH

30:1

SCREW MATERIAL

SACM-645/38 CRMOALA

CYLINDER MATERIAL

SACM-645/38 CRMOALA

CYLINDER COOLING

550WX3

550wX3

750wX4

750wX4

DRIVING MOTOR(Kw)

37

55

75

90

TEMPERATURE CONTROL

4

4

5

5

AVERAGE POWER-CONSUME(Kw)

45

65

90

110

TYPE OF DIE

DIE SIZE(mm)

350/400

400/500

500/600

500/600

TEMPERATURE CONTROL

3

4

4

5

AIR RING

1

AIR BLOWER(Kw)

3

5.5

7.5

11

TAKE-UPUNIT

PINCH ROLLER (DIA. WIDTH)mm

Φ165X1600

Φ190X2200

¦Φ190X2700

Φ220X3500

TAKE-UP SPEED(m/min)

5-60

5-60

5-60

5-60

TAKE-UP MOTOR(Kw)

1.5

1.5

2.2

2.2

WINDING UNIT

TYPE

SURFACE FRICTION TYPE

WINDING MOTOR(Kw)

1.5

1.5

2.2

2.2

WINDING SPEED(m/min)

5-60

5-60

5-60

5-60

COVER DIMENSION(m)

6.8X2.6X6.5

7.5X3.2X7.5

9.0X4.2X10

11X5.0X11.5





Packaging & Shipping



MOQ

1 set (more than 3 sets, please ask us for discount)

Delivery time

20-50 days after receipt of deposit

Delivery Clause

FOB Ningbo Port

Terms of payment

T/T, L/C at sight

Installation

 If need our engineer go to your country to install, please repare the material and bulid machine firstly.

Also buyer should take charge the tickets go and back, live, food and salary of our engineer.

Guarantee

One year, machine trouble is caused by nature not by human force from delivery time .

 Easily wear parts also is one year

After sale service

Free service of machine warranty by one year from the date of delivery;

paid service after service period,the labor and parts costs are charged.









FAQ



1.   Q: Are you a factory or trading company?

A:We are factory .we are film extrusion machines,printing machines,bag making machines,slitting machines and other related machines manufacturer nearly 20 years.

2. Q: Where is your factory located? How can I visit there?

A:Our factory is located in Rui'an City, Zhejiang Province, China.The nearest airport is Wenzhou airport,From Shanghai to Wenzhou by air about 1 hour.we can go Wenzhou airport pick you.

3. Q: How about you to keep the quality and th after—sales service?

A:Our idea is“QUALITY IS THE FIRST IS THE MAOST IMPORTANT".We insit for the long time business, not once time business. From beginning to end, we will reply and try to solve within 12 hours.

4. Q: How about the payment term?

A: For new customer, our payment terms is 30% T/T in advance before production, the balance 70% should be paid before delivery.

5. What about warranty and do the engineers available to overseas?

A: One year warranty. During this period, if the machine has some problems, our engineers can go abroad to fix for you.But buyer need provided the ticket,food,hotel cost etc.

6.What about the service after sale?

A: One you have bought our machine, you can call us or email us telling us the machine problems and any questions about the machines. We will reply to you with 12 hours and help you to slove the problem.

7.How about machine testing?

A: If you come,we will test machine with you toghther,If you need special material to test,please take it.If you cant come.we will test it by ourselves and send the video to you for your reference.
