YF-FE Double Layer Color Master Lab Extruder

YF-FE Double Layer Color Master Lab Extruder photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Film
Plastic Processed PE
Blow Moulding Type Extrusion Blow Moulding
Automatic Other, FILM BLOWER
Place of Origin Zhejiang, China
Brand Name YUNFENG
Model Number YF-FE
Voltage 220v 380v 440v
Power(W) 15kw 22kw
Dimension(L*W*H) 4800*1900*4100mm
Weight 2T 2.5T 3T
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas



YF-FE Color Master Lab Extruder

YF-FE Double layer Color Master Lab Extruder

 YF-FE Double layer Color Master Lab Extruder



  Main Technical Variables:

Model

SJ-40×2FM600

SJ-45×2FM800

Suitable Material

HDPE

Film Width

200-600

300-800

Film Thickness

0.008-0.06mm

0.008-0.06mm

Max.Extrusion Output

45kg/hr

55kg/hr

EXTRUDER





Screw Diameter

40+40mm

45+45mm

Screw L/d Length

28:1

Screw  Material

38CRMOALA

Cylinder Material

38CRMOALA

Cylinder Cooling

370w*2

370w*2

Driving  Motor

15kw

18.5kw

Temperature Control

3+3

3+3

Average Power-consume

20kw

28kw

Type of die



Die size mm

70

100

Temperature  control

2

Air   ring

1

Air  blower

2.2kw

Center steady  stick(HD)

1

Take-upunit



Roller  width

165*650

165*850

Take-up  speed

10-100m/min

10-100m/min

Take-up motor

0.75kw

1.5kw

Height  adjustable  type

700mm

700mm

Winding  unit



Type

Surface friction type

Winding  motor

6kw

6kw

Wingding  speed

100m/min

100m/min

Outline  diameter(L*W*H)

5.0*2.0*4.1

5.5*2.0*4.1



Packaging & Shipping



MOQ

1 set (more than 3 sets, please ask us for discount)

Delivery time

20-50 days after receipt of deposit

Delivery Clause

FOB Ningbo Port

Terms of payment

T/T, L/C at sight

Installation

 If need our engineer go to your country to install, please repare the material and bulid machine firstly.

Also buyer should take charge the tickets go and back, live, food and salary of our engineer.

Guarantee

One year, machine trouble is caused by nature not by human force from delivery time .

 Easily wear parts also is one year

After sale service

Free service of machine warranty by one year from the date of delivery;

paid service after service period,the labor and parts costs are charged.









FAQ



1.   Q: Are you a factory or trading company?

A:We are factory .we are film extrusion machines,printing machines,bag making machines,slitting machines and other related machines manufacturer nearly 20 years.

2. Q: Where is your factory located? How can I visit there?

A:Our factory is located in Rui'an City, Zhejiang Province, China.The nearest airport is Wenzhou airport,From Shanghai to Wenzhou by air about 1 hour.we can go Wenzhou airport pick you.

3. Q: How about you to keep the quality and th after—sales service?

A:Our idea is“QUALITY IS THE FIRST IS THE MAOST IMPORTANT".We insit for the long time business, not once time business. From beginning to end, we will reply and try to solve within 12 hours.

4. Q: How about the payment term?

A: For new customer, our payment terms is 30% T/T in advance before production, the balance 70% should be paid before delivery.

5. What about warranty and do the engineers available to overseas?

A: One year warranty. During this period, if the machine has some problems, our engineers can go abroad to fix for you.But buyer need provided the ticket,food,hotel cost etc.

6.What about the service after sale?

A: One you have bought our machine, you can call us or email us telling us the machine problems and any questions about the machines. We will reply to you with 12 hours and help you to slove the problem.

7.How about machine testing?

A: If you come,we will test machine with you toghther,If you need special material to test,please take it.If you cant come.we will test it by ourselves and send the video to you for your reference.
