ZG Automatic Small Vibrating Feeder With 5-8% off for X'mas

Specifications

1.ISO 9001:2008 patent vibrating feeder
2.AAA grade reputable enterprise
2.Large Capacity:40-700t/h
3.Max Feeding Size:1200mm

Company introduction

Xinxiang dingli mining equipment company established in 2003 and have over 20 years' experience in stone proccesing line

we major in jaw cusher, patented hammer crusher, cone crusher, impact crusher vibrating screen and feeder, drilling rig, impactor and so on





Perfect design------ Automatic Small Vibrating Feeder with 5-8% off for X'mas :



Our vibrating feeder adopts linear vibrating feeding and the whole-base structure. Though the stepless adjustment the angle of eccentric block, you can control the vibrating strength conveniently and the amounts of feeding.





Advantages------ Automatic Small Vibrating Feeder with 5-8% off for X'mas :



  It is steady vibrating, reliable working, flexible adjustment, easy installment and so on. It is efficient to reduce the working cost and the pressure of workers, so it is the perfect machine as the continual and uniform feeder for stone crusher.





Warranty------ Automatic Small Vibrating Feeder with 5-8% off for X'mas :



1. We always offer our machine on the base of the result from our test basis, the feedback from our clients, and the research from our R&D, so we can guarantee the quality and function of our machine. We have more than 160 excellent and diligent workers and based on the advanced equipment so we can deliver the order on time and can meet the urgent requirements on terms.



2. We have many high quality installers; they are ready to serve you all the time. We have the best after-sale service, based on these terms, we are developing all the time and our scale is enlarging gradually.



Working site------ Automatic Small Vibrating Feeder with 5-8% off for X'mas :



Main technical parameters------ Automatic Small Vibrating Feeder with 5-8% off for X'mas :



Types	Chute size (mm)	Max feeding size(mm)	Capacity (t/h)	Matched motor Motor size Strength (KN)	Power (kw)
ZG-0728	710×2800	400	40-80	YZU-20-6 20	1.5×2
ZG-0828	810×2800	450	60-100	YZU-30-630 30	2.2×2
ZG-0928	850×2800	500	80-120	YZU-40-640 40	3×2
ZG-1028A	970×2800	600	150-200	YZU-40-640 40	3×2
ZG-1028B	1000×2800	650	150-200	YZU-40-640 40	3×2
ZG-1128	1070×2800	700	200-250	YZU-50-650 50	3.7×2
ZG-1228	1255×2800	750	220-270	YZU-50-650 50	3.7×2
ZG-1328	1255×2800	800	220-280	YZU-75-650 50	4×2
ZG-1428	1350×2800	900	260-320	YZU-75-675 75	5.5×2
ZG-1528	1500×2800	1000	300-400	YZU-75-675 75	5.5×2
ZG-2028	2000×2800	1200	500-700	YZU-100-6 100	7.5×2



Notes: the ZG series vibrating feeder have the similar model, if there is a need, please contact us for the details.
