Help CenterHigh Quality Rubber Belt Conveyor Used in Quarry and Mining Industry
Related Products
-
Quarry and Mine Crusher Quarry ConveyorUS$ 1 - 420MOQ: 15 Meters -
Quarry and Mine Vibrating Screen ConveyorUS$ 1 - 420MOQ: 15 Meters
-
Quarry and Mine Inclined Conveyor Belt ConveyorUS$ 1 - 420MOQ: 15 Meters
-
Sand and Gravel Conveyor Belt for Mining in High DurabilityUS$ 1 - 420MOQ: 15 Meters
-
Quarry and Mine Environmental Inclined 17 Degree Band ConveyorUS$ 1 - 420MOQ: 15 Meters
Specifications
Rubber Belt Conveyor1.AAA grade reputable enterprise
2.Belt width:400-1200mm
3.Large capacity:40-1284t/h
4.ISO9001:2008,TUV
1.Classification------High quality rubber belt conveyor:
Conveyor can be horizontal, tilt and vertical transmission, but also the composition of space transmission lines, transmission lines are generally fixed.
Conveyor transport capacity, long-distance, but also in the transportation process while completing a number of process operation, it is widely used. Main belt conveyor, plate conveyor, scraper conveyor, bucket conveyor, bucket elevator, overhead conveyors and so on.
2.Application------High quality rubber belt conveyor:
Belt conveyor is widely used in mining, gravel field, metallurgy, building materials, chemical industry, mineral processing, coal mining and other industries transport material.
3.Work Environment------High quality rubber belt conveyor:
Belt conveyor, belt conveyor for conveying bulk density of less than 1.67 / t / cubic meter, easy to dig a powder, granular, small block of low-abrasive materials and bags of materials, such as coal, gravel, sand, cement, fertilizer, and grain. Sent material temperature is less than 60 °C.
The form of their captain and assembly can be determined according to user requirements, transmission can be electric drum can also be used with a drive rack drive.
4.Main technical parameters------High quality rubber belt conveyor:
|
Belt Width (mm) |
Belt Length(m) / Power(kw) |
Belt Speed (m/s) |
Capacity (t/h) |
||
B400 |
≤12/1.5 |
12-20/2.2 |
20-25/3 |
0.8-2 |
40-80 |
B500 |
≤12/3 |
12-20/4 |
20-30/5.5 |
0.8-2 |
78-191 |
B650 |
≤12/4 |
12-20/5.5 |
20-30/7.5 |
0.8-2 |
131-323 |
B800 |
≤10/4 |
10-15/5.5 |
15-25/7.5 |
1.0-2 |
278-546 |
B1000 |
≤10/5.5 |
10-20/7.5 |
20-25/11 |
1.0-2 |
435-853 |
B1200 |
≤10/7.5 |
10-20/11 |
20-25/15 |
1.0-2 |
655-1284 |
services before the sale,we do
Act as a good adviser and assistant of clients; enable them to get rich and generous returns on their investments;
1. Select equipment model;
2.Sdeign and manufacture products according to clients' special requirement;
3. Train technical personnel for clients.
services during the sale,we do
Respect clients; devote ourselves to improving the total value of clients.
1. Pre-check and accept products ahead of delivery;
2. help clients to draft solution.
after-sale services ,we do
Provide considerate services to minimize clients' worries.
1. Assist clients to prepare for the first construction scheme;
2. Install and debug the equipment;
3. Train the first-line operators on site;
4. Examine the equipment regularly;
5. Take initiative to eliminate the troubles rapidly at site;
6. Distribute the guarantee fittings door-to-door;
vide perfect service;
8. Provide technical exchanging;
9. Provide maintenance for big items
Company introduction
Xinxiang dingli mining equipment company established in 2003 and have over 20 years' experience in stone proccesing line
we major in jaw cusher, patented hammer crusher, cone crusher, impact crusher vibrating screen and feeder, drilling rig, impactor and so on
