Sand and Gravel Conveyor Belt for Mining in High Durability

Name: Sand and Gravel Conveyor Belt for Mining in High Durability
Brand: Dingli
SKU: 102490465
Availability: InStock

US$ 1 - 420 MOQ: 15 Meters

Key Specifications

Condition:

New

Type:

Other, Gravity Conveyor, Fixed band conveyor

Material:

Rubber

Xinxiang Dingli Mine Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Chinese main port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Gravity Conveyor, Fixed band conveyor

Material Rubber

Material Feature Heat Resistant

Structure Other, Belt Conveyor, U-bar,Angle iron frame

Load Capacity 40-1200t/h

Place of Origin Henan, China

Brand Name Dingli

Model Number B series

Specifications

Sand and Gravel Conveyor Belt for Mining
1.500-1200belt conveyor
2.Quarry&mine belt conveyor
3.Large capacity

Introduction------ Sand and Gravel Conveyor Belt for Mining :

Belt conveyor is machinery driven by friction for continual transportation of materials. It can form a flow line from beginning and end when working.
It not only can convey the crushed materials, but also convey by piece. It can cooperate with the requirement of every industry to build a flow line, except that it conveys the bulk materials.

Application------ Sand and Gravel Conveyor Belt for Mining :

Belt conveyor extensively used in modern industry such as mine tunnel, mine open-air conveying system, open-air quarry and beneficiation.
It is very convenient for horizontal, inclined conveying

Characters------ Sand and Gravel Conveyor Belt for Mining :

The main character of Belt conveyor is convenient to stretch for the belt-save space.
The end can be stretched according to the working spot.
Its structure is very compact, light frame, convenient to install and dismantle.
When load more materials or long term conveying, it can set a motor in the middle.
As your requirement, you can convey with one conveyor or use multi-conveyor for a system to convey the materials
Figure belt conveyor throughput in the density of materials for the 1.0t / m ^ 3 ~ 1.6t / m ^ 3, conveyor angle ≤ 18 °, packing materials for the 30 ° angle of the conditions reached.
The density of materials can be delivered in the 2.5t / m ^ 3 below.
Conveyor belt conveyor length is not limited to the value listed in the table, based on the user's need for manufacturing.

Technical parameter------ Sand and Gravel Conveyor Belt for Mining :

Width B(mm)		500			650			800			1000			1200			1400(1600)
Edge height H(mm)		80	120	160	80	120	160	120	160	200	160	200	240	200	240	300	200	240	300	400
Diaphragm plate height (mm)		75	110	150	75	110	150	110	150	180	150	180	220	180	220	280	180	220	280	360
Speed V(m/s)		0.8 1.0 1.25 1.6 2.0 2.5 3.15 4.0
Drum diameter (mm)		400,500			400,500,630			500,630,800			630,800,1000			630,800,1000,1250			800,1000,1250,1400
Veer Drum diameter (mm)		400			400,500			400,500,630			500,630,800			500,630,800,1000			630,800,1000,1250
Roller (mm)		Φ89									Φ108
Normal angle		0-30° 30° 40° 45° 50° 55° 60° 65° 70° 75° 80° 85° 90°
Angle range		0-90°
Transmission	Type I	Motorized pulley(with brake)
	Efficacy KW	1.5-7.5						1.5-11			1.5-37			1.5-90			1.5-110
	Type II	Y motor +V belt + axis redactor(with brake)+driving drum
	Efficacy KW	3-11						3-15			3-22
	Type III	Motor +coupling + redactor + driving drum(with brake)(By a single motor drive)
	Efficacy KW	1.5-30						1.5-55			2.2-90			4-110			5.5-185
