Specifications
Evironmental complete quarry long conveyor:1.500-1200belt conveyor
2.quarry&mine belt conveyor
3.Large capacity
Belt conveyor,conveyor belt, belt machine
(1)belt conveyor Classification:
Conveyor can be horizontal, tilt and vertical transmission, but also the composition of space transmission lines, transmission lines are generally fixed. Conveyor transport capacity, long-distance, but also in the transportation process while completing a number of process operation, it is widely used. Main belt conveyor, plate conveyor, scraper conveyor, bucket conveyor, bucket elevator, overhead conveyors and so on.
(2)belt conveyor Used in:
Belt conveyor is widely used in mining, gravel field, metallurgy, building materials, chemical industry, mineral processing, coal mining and other industries transport material.
(3)belt conveyor Work environment:
Belt conveyor, belt conveyor for conveying bulk density of less than 1.67 / t / cubic meter, easy to dig a powder, granular, small block of low-abrasive materials and bags of materials, such as coal, gravel, sand, cement, fertilizer, and grain. Sent material temperature is less than 60 °C. The form of their captain and assembly can be determined according to user requirements, transmission can be electric drum can also be used with a drive rack drive.
(4)Belt Conveyor Main technical parameters:
Tape Width (mm) |
Belt Length (m) / Power (kw) |
Conveyor speed (m/s) |
Throughput (t /h) |
||
500 |
≤12/3 |
12-20/4-5.5 |
20-30/ 5.5-7.5 |
1.3-1.6 |
45-100 |
650 |
≤12/4 |
12-20/5.5 |
20-30/7.5-11 |
1.3-1.6 |
70-120 |
800 |
≤6/4 |
6-15/5.5 |
15-30/7.5-15 |
1.3-1.6 |
120-180 |
1000 |
≤10/5.5 |
10-20/7.5-11 |
20-40/11-12 |
1.3-2.0 |
160-250 |
1200 |
≤10/7.5 |
10-20/11 |
20-40/15-30 |
1.3-2.0 |
200-400 |
