Specifications
1) Intergrative design, compact structure.
2) Same configuration and good quality, competitive price.
3) One year warranty, engineers available to service machinery overseas.
Mould Laser welding machine laser welder
Technology Parameter:
| Model | HL-M-W200 |
| The maximum laser power | 200W |
| Laser wavelength (nm) | 1064 |
| Single pulse energy | 110J |
| Laser welding frequency(HZ) | 0.5-40 |
| Laser welding depth (mm) | 0.1-3 |
| Pluse width (ms) | 0.5-20 |
| Spot size (mm) | 0.2-2 |
| Laser welding wire (mm) | 0.2-0.8 |
| Rated power | 3KW |
| The workbench | strengthen automatic table, optional electric table |
| Power requirements | 15% of single-phase 220 VAC, ... 50Hz 30A |
Product advantages:
1. A newly designed, high taste and appearance
2. The laser head up and down, around, move around, up and down and around the auto-mobile, suitable for large-scale mold, operability greatly improve.
3. The independent design of the laser path and the power control system for easy mobility, suitable for a variety of venues all kinds of mold repair.
4. Enhanced automatic precision stage, an optional upper and lower motor control, variable speed. Table horizontal direction with ball screws, welding of large mold, table operations can be easily moved and has a very high precision and stability.
5. Laser control for precision control of laser power waveform, different material presets optimized waveform value. Select the corresponding material can be welded to the best effect.
6. The heat affected zone is small, does not lead to the deformation of the precision instruments, welding depth and welding firm, fully melted, without leaving patches traces bath dissolved material protruding part of the substrate at the non-convex subsidence phenomenon.
Observation system:
Equipped with the crosshairs special microscope magnification of 17.5X. Cross cursor Center and the laser spot center alignment (user adjustable). With high-speed electronic filter protection device to protect the operator eyes laser injury, relieve the operator eye fatigue, improve work efficiency.
Control system:
Improved built-in single-chip dual-precision closed-loop control. Its stability and ability run far better than similar products with using a small computer controlled card.
1.Air or Sea shipping,Cheap Price, but will take a little more time to reach you.
2.Equipment will be packed into the standard wooden cartons, suitable for vessel or air transport, and marked the universal label, shipping marks etc.
(1) Warranty and Service included:
a. Hardware: 1 year on all parts and labor;
b. Software: whole life on update for free.
c. Maintenance and technological support: whole life.
(2) Training:
a. 3--4 days free training for the whole system in Seller’s company.
b. If customer needs our technician give the training abroad, the customer need charge for the transportation and accommodation fees of engineer;
Including: how to set up the equipment;
how to debug the light route;
how to use the software and operate the equipment;
how to replace the bad material and spare parts, etc;
how to maintain the equipment;
how to estimate and settle the problem, and analysis the reason.
1.Q: How can you guarantee that I have a good sale on this product?
A: Our products are professional, high quality and competitive price. We also offer professional technology and after-sale service.
2. Q: How can I get the sample to check the quality?
A: If you want to mark sample to check the quality, pls kindly send us the sample for testing.
3. Q: How long can I expect to get the sample?
A: We ensure that the marking samples could be done within 1-2 days once we receive the sample from your side.
Pls let us know:
1. What kind of machine you need?
2. The information about the material you want to process.
3. What is your business scope? Are you end user or distributor?
We will be very happy to help you in any way we can. Pls don't hesitate to LEAVE MESSAGE to me.
